Light Duty Mine Articulated Underground Articulated Truck 3 Ton
Light Duty Mine Articulated Underground Articulated Truck 3 Ton
Light Duty Mine Articulated Underground Articulated Truck 3 Ton
Light Duty Mine Articulated Underground Articulated Truck 3 Ton
Light Duty Mine Articulated Underground Articulated Truck 3 Ton
Light Duty Mine Articulated Underground Articulated Truck 3 Ton
Light Duty Mine Articulated Underground Articulated Truck 3 Ton
Light Duty Mine Articulated Underground Articulated Truck 3 Ton
Light Duty Mine Articulated Underground Articulated Truck 3 Ton
Light Duty Mine Articulated Underground Articulated Truck 3 Ton
Light Duty Mine Articulated Underground Articulated Truck 3 Ton
Light Duty Mine Articulated Underground Articulated Truck 3 Ton
Specifications
Brand Name :
Beijun
Model Number :
UQ-3
Certification :
CE,ISO
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C, T/T
Supply Ability :
1000 Set/Sets per Month
Delivery Time :
7-14 days
Packaging Details :
Customized packaging
Engine Model :
CHANGCHAI 490
Engine Power :
63 HP
Transmission Model :
Ningjing 130
Drive Mode :
4x4
Dimension of Bottom Spring Plate :
Length 71mm, Width 11mm
Loading Capacity :
3 Tons
Description

Product parameters of 3 Ton Dump Truck

1. Four wheels adopt wet braking, effectively ensuring safety during use

2. Adopting a pneumatic clutch booster, easy, effective, and reliable

3. Hydraulic steering system for easy and stable operation, reducing labor intensity

4. Double oil cylinder self unloading device, high safety and stability

5. Special leaf spring for underground mining trucks, durable and reliable

6. Low profile design, small turning angle, and strong passing ability

7. Special industrial and mining facilities can adopt a middle driving ultra low design, which can meet the normal use of a height of 1.55 meters.

Model UQ-3
Engine Model CHANGCHAI 490
Engine Power 63 HP
Transmission Model Ningjing 130
Transmission Gear 4 Forward Gear, 1Back Gear,Rear High Speed Controller
Drive Mode 4x4
Front Axle Model CHITONG ISUZU Axle
Rear Axle Model CHITONG ISUZU Axle
Tire Model 700x16 Line Tire,
Rear Single Tyre One Side,
No.of Bottom Spring Plate Front 7 PCS, Rear 8 PCS, Spare 6PCS
Dimension of Bottom Spring Plate Length 70mm, Width 10mm
Size of the Bucket:Length×width×height 2401mm*1301mm*451mm
Type of Bucket U type Bucket
Thickness of Bucket Steel Plate bottom 6mm side 4mm
Unloading Type Hydraulic Double Top Dump
Steering Type Hydraulic power steering
Braking Type Air Brake
Cabin Canopy
Driving Position Left Hand Drive
Cooling sytem Standard Water Cooling System
Loading Capacity 3 Tons
