Magnetic Method F1 Coating Thickness Probe Fit For Coating Thickness Gauge TM510FNPLUS
Magnetic Method F1 Coating Thickness Probe Fit For Coating Thickness Gauge TM510FNPLUS
Magnetic Method F1 Coating Thickness Probe Fit For Coating Thickness Gauge TM510FNPLUS
Magnetic Method F1 Coating Thickness Probe Fit For Coating Thickness Gauge TM510FNPLUS
Specifications
Brand Name :
TMTeck
Model Number :
F1
Place of Origin :
China
MOQ :
1
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
50PCS/Two weeks
Delivery Time :
3-5 work day
Packaging Details :
Carton 20*15*12cm 0.5kg
Description

F1 Coating thickness probe

Information:

Probe F400 F5 F1 F1/90° F10
Measuring Principle Magnetic method
Measuring range(mm) 0～400um 0～1250 um 0～10000
Min resolution(mm) 0.1 0.1 10
Tolerance One-point calibration (mm) ±(2%H+0.7) ±(2%H+1) ±(2%H+10)
Two-point calibration (mm) ±(1%H+0.7) ±((1%H+1) ±(1%H+10)
Minimum radius of curvature (convex) (mm) 1 1.5 1.5 flat 10
Minimum measuring area(mm) F3 F7 F7 F40
Minimum thickness of base material(mm) 0.2 0.5 0.5 2

Magnetic Method F1 Coating Thickness Probe Fit For Coating Thickness Gauge TM510FNPLUS

Magnetic Method F1 Coating Thickness Probe Fit For Coating Thickness Gauge TM510FNPLUS

Magnetic Method F1 Coating Thickness Probe Fit For Coating Thickness Gauge TM510FNPLUS

Magnetic Method F1 Coating Thickness Probe Fit For Coating Thickness Gauge TM510FNPLUS
