High compatibility Acoustic TS21 A14 Corrosion Probe
High compatibility Acoustic TS21 A14 Corrosion Probe
Specifications
Brand Name :
TMTeck
Model Number :
TS21 A14
Place of Origin :
China
MOQ :
1
Price :
Negotiation
Payment Terms :
T/T, Western Union,paypal
Supply Ability :
100pcs/ one week
Delivery Time :
25 work days
Packaging Details :
carton
Type :
phased array probe
Element :
60
Element Shape :
Concave
Size :
LxWxH 68x23x20(mm) 2.68x0.91x0.79(in)
Application :
Oil and gas: oil pipelines, bottles, tanks, etc.
Color :
Sliver
Description

High compatibility Acoustic TS21 A14 Corrosion Probe

Corrosion Probes: Corrosion Probes detect wall thickness reduction caused by corrosion, erosion, etc., and can detect damage in the wall.

Advantages

1.High compatibility, can be compatible with most phased array flaw detectors.

2.The combination of s19 and s20 can automatically detect the girth weld, which is suitable for manual or automatic inspection of pipeline welds.

3. S20 is internal focus probeto optimize the signal to noise ratio

4.Good beam energy in the detection of small pipe/thin wall samples

5.Acoustic, can be matched with Rexolite, can complete most angles of sound beam

6.Can detect thick flat materials and welds, forgings, noise or granular materials

Applications

1. Oil and gas: oil pipelines, bottles, tanks, etc.

2. Electricity: pressure vessels and pipelines, turbine blades, rotor monitoring, etc.

3. Other: testing of thick welds, pipe welds, etc.

Specification

Probe
Series		 Model

Compatible

Model

 Element
Shape		 Freq (MHz) E-Nos Pitch
(mm)

Active
Aperture

(mm)

Elev.

(mm)

 Size(LxWxH)
TS21/A14 2.25L60-1.0x10 2.25L60-60x10 Linear 2.25 60 1.00 60.0 10.0

68x23x20

(mm)
2.68x0.91x0.79

(in)
3.5L60-1.0x10 3.5L60-60x10 Linear 3.5 60 1.00 60.0 10.0
5L60-1.0x10 5L60-60x10 Linear 5 60 1.00 60.0 10.0
7.5L60-1.0x10 7.5L60-60x10 Linear 7.5 60 1.00 60.0 10.0
10L60-1.0x10 10L60-60x10 Linear 10 60 1.00 60.0 10.0

*The standard cable length is 2.5m/8.2ft. The phased probe can be customized,include frequency, element number and pitch,etc.

Wedge Specification

Probe Series Model Compatible Model Element Shape Size(LxWxH)
TS21/A14 N0L 0°LW 40°~70°

68x23x20

(mm)
2.68x0.91x0.79

(in)
N60L 60°LW 40°~70°
N55S 55°SW 40°~70°

Quick Details

Model Number:5L60-1.0x10-TS21/5L60-60x10-A14

Element:60

Element Shape:liner

Size:LxWxH 68x23x20(mm) 2.68x0.91x0.79(in)

Application:Oil and gas: oil pipelines, bottles, tanks, etc.

Warranty:12 Months

Case:Stainless steel

Customization:yes

Type:phased array probe

Color:Silver

MOQ:1
