High Sensitivity Coating Thickness Tester Portable With Wide Measuring Range MCT200
High Sensitivity Coating Thickness Tester Portable With Wide Measuring Range MCT200
High Sensitivity Coating Thickness Tester Portable With Wide Measuring Range MCT200
High Sensitivity Coating Thickness Tester Portable With Wide Measuring Range MCT200
High Sensitivity Coating Thickness Tester Portable With Wide Measuring Range MCT200
High Sensitivity Coating Thickness Tester Portable With Wide Measuring Range MCT200
High Sensitivity Coating Thickness Tester Portable With Wide Measuring Range MCT200
High Sensitivity Coating Thickness Tester Portable With Wide Measuring Range MCT200
Specifications
Brand Name :
MITECH
Model Number :
MCT200
Certification :
CE / GOST
Place of Origin :
China Beijing
MOQ :
1 piece
Payment Terms :
T/T, Western Union, Paypal
Supply Ability :
500 Unit/Units per Month
Delivery Time :
after receiving payment
Packaging Details :
Standard export carton
Measuring range :
0～1250) μm, depends on probes. maximum 10mm for the probe F10.
Resolution :
0.1μm
Accuracy :
±(3%H+1) μm
Display :
4 digital LCD with EL backlight
Description

Mitech MCT200 Coating Thickness Tester with high sensitivity and accuracy , compatible different probe

Overview

This compatible, handy pocket gauge is designed for non-destructive, fast and precise coating thickness measurement. It is ideal for manufactures and their customers, for offices and specialist advisers, for paint shops and electroplates, for the chemical, automobile, shipbuilding and aircraft industries and for light and heavy engineering.

High Sensitivity Coating Thickness Tester Portable With Wide Measuring Range MCT200

Technical Parameters

Low range resolution

0.1μm

Display

4 digits LCD with EL back-light

Unit system

Metric(μm),Imperial(mil)

Communication

USB1.1

Dimensions

125mm×67mm×31mm

Weight

340g

Working Principle

Measuring principle: Magnetic induction & Eddy current.

With different external probes, the gauge can be applied to measuring thickness of non-magnetic coating on magnetic Metal substrate,as well as non-conductive coating on non-magnetic metal substrate.

Structure of The Main Unit

High Sensitivity Coating Thickness Tester Portable With Wide Measuring Range MCT200

1.The main body 2.Key pad 3.LCD

4.Battery cover 5.Probe socket 6.USB port

7.Label

High Sensitivity Coating Thickness Tester Portable With Wide Measuring Range MCT200
