3.5-inch Color Touchscreen Panel
- Real-time display of frequency, power (0-100% adjustable, accuracy ±0.5%), temperature (ambient-60°C, PID temperature control ±1°C), and cleaning time (1-30 minutes);
- Presets 3 major modes: "Eyeglass Cleaning", "Jewelry Maintenance", and "Instrument Precision Cleaning":
- Eyeglass Mode: 35KHz + 40% power + 35°C, removes lens grease and nose pad sweat stains in 3 minutes;
- Instrument Mode: 25KHz + 70% power + 45°C, dissolves oil and bacteria on the inner walls of wind instruments in 8 minutes.
Energy-saving and Safety Design
- Automatic sleep mode after 10 minutes of inactivity (power consumption ≤3W), annual power consumption <10 kWh;
- Overload protection (power off when current exceeds 110%) + dry burn prevention monitoring, compliant with CE and RoHS certifications, suitable for both household and professional environments.
Deep Cleaning Effects
- Daily Scenarios:
- Eyeglasses: Light transmittance increased to 98% after cleaning, fingerprint residue ≤0.1%;
- Silver jewelry deoxidation: 40KHz + 50% power + 30°C, restores glossiness ≥95% in 5 minutes;
- Professional Scenarios:
- Violin peghead cleaning: 28KHz + 60% power + 40°C, combined with special instrument cleaning agent, completely removes rosin buildup and restores peg smoothness;
- Woodwind instrument key pad cleaning: 33KHz pulse mode (3-second interval), protects rubber pads from damage, bacterial removal rate ≥99%.
Thoughtful Detail Configurations
- Medical-grade cleaning basket: Grid bottom tray (3mm aperture) prevents small items from falling, with a silicone non-slip layer on the basket body;
- Detachable filter: 25μm precision traps jewelry polishing powder and instrument debris, can be directly removed and emptied during maintenance without disassembling the machine.
Digital Black Titanium Series | | | | | | | |
Model | Capacity | Ultrasonic power | Heating power | Cleaning tank size | Overall dimensions of the machine | Gross Weight | Large box size |
L | W | W | (LⅹwⅹH)mm | (LⅹwⅹH)mm | KG | (LⅹwⅹH)mm |
JPS-08AH | 1.3L | 60 | 100 | 150×140×65 | 180×170×140 | 3.2 | 526×524×308(4Table) |
JPS-10AH | 2L | 80 | 100 | 150x140x100 | 180x170x180 | 4.1 | 526×524×338(4Table) |
JPS-20AH | 3L | 120 | 100 | 240x135x100 | 270x170x210 | 4.5 | 410×335×345(2Table) |
JPS-30AH | 6L | 180 | 300 | 300x150x150 | 330x180x270 | 9.8 | 555×435×390(2Table) |
JPS-40AH | 10L | 240 | 300 | 300x240x150 | 330x270x270 | 17.5 | 735×435×380(2Table) |
JPS-50AH | 14L | 300 | 300 | 300×240×200 | 330×270×320 | 21.5 | 420×360×420(1Table) |
JPS-60AH | 15L | 360 | 300 | 330×300×150 | 360×330×270 | 21.5 | 450×420×370(1Table) |
JPS-70AH | 19L | 420 | 300 | 330×300×200 | 360×330×320 | 24.5 | 460×420×420(1Table) |
JPS-80AH | 22L | 480 | 600 | 488×288×150 | 550×330×270 | 29.0 | 625×420×370(1Table) |
JPS-100AH | 30L | 600 | 600 | 488×288×200 | 550×330×320 | 33.0 | 625×420×420(1Table) |
