- Fully Digital Intelligent Power Regulation System — Output on Demand, Precise Energy Control
0 - 100% Steplessly Adjustable Power:
Equipped with a Digital Signal Processor (DSP), it supports fine - tuning of power at the 0.1% level. For example, when cleaning precision parts, the power can be set to 30% to prevent damage, while for degreasing hardware parts, it can operate at full power. This improves the adjustment accuracy by 5 times compared with traditional knob - type regulation.
It can display the power waveform diagram in real - time (with a resolution of 10ms) and automatically compensate for power grid fluctuations. When the voltage fluctuates by ±10%, the power stability is ≥99%, avoiding the impact of power drift on the cleaning effect.
100 Groups of Intelligent Recipe Storage: The 7 - inch color touch screen supports the presetting of cleaning parameters (power, frequency, time, temperature), which can be called up with one click to adapt to different workpieces. For example:
- For cleaning eyeglass lenses: 40KHz + 40% power + warm water at 35℃, which can remove oil stains without damaging the coating in 5 minutes;
- For degreasing automotive parts: 28KHz + 80% power + hot washing at 60℃, which can strip stubborn cutting fluids in 15 minutes.
Upgraded Structural Materials:
- Inner tank: Made of 304 stainless steel (2mm thick) with one - piece molding. The welds are inspected by X - ray flaw detection and helium mass spectrometry leak detection (leakage rate ≤ 0.1mbar・L/s). It is resistant to acids and alkalis with a pH range of 2 - 13, suitable for cleaning agents such as hydrochloric acid and sodium hydroxide.
- Outer shell: Cold - rolled steel plate with electrostatic powder coating (hardness ≥ 2H). It is available in black titanium and industrial gray color schemes. Four sets of 30mm height - adjustable feet are installed at the bottom to adapt to uneven ground (leveling accuracy ±2mm).
Digital Power Adjustment Series | | | | | | | |
Model | Capacity | Ultrasonic power | Heating power | Cleaning tank size | Overall dimensions of the machine | Gross Weight | Large box size |
L | W | W | (LⅹwⅹH)mm | (LⅹwⅹH)mm | KG | (LⅹwⅹH)mm |
JPS-20AL | 3L | 50~120 | 100 | 240x135x100 | 270x170x210 | 4.1 | 410×355×345(2Table) |
JPS-30AL | 6L | 70~180 | 300 | 300x150x150 | 330x180x270 | 6.3 | 555×435×390(2Table) |
JPS-40AL | 10L | 100~240 | 300 | 300x240x150 | 330x270x270 | 8.5 | 735×435×380(2Table) |
JPS-50AL | 14L | 120~300 | 300 | 300×240×200 | 330×270×320 | 10.5 | 420×360×420(1Table) |
JPS-60AL | 15L | 150~360 | 300 | 330×300×150 | 360×330×270 | 10.5 | 450×420×370(1Table) |
JPS-70AL | 19L | 170~420 | 300 | 330×300×200 | 360×330×320 | 12.0 | 460×420×420(1Table) |
JPS-80AL | 22L | 200~480 | 600 | 500×300×150 | 550×330×270 | 14.0 | 625×420×370(1Table) |
JPS-100AL | 30L | 240~600 | 600 | 500×300×200 | 550×330×320 | 16.0 | 625×420×420(1Table) |
