14 Liter Multifunctional Ultrasonic Degassing Cleaner, 120W to 300W Variable Power Dual Use Washing Equipment for Auto Components & Medical Surgical Instruments
14 Liter Multifunctional Ultrasonic Degassing Cleaner, 120W to 300W Variable Power Dual Use Washing Equipment for Auto Components & Medical Surgical Instruments
Specifications
Model Number :
JPS-50AL
Product Series :
Digital Power Adjustment Series
Brand Name :
JeiTai
Heating power :
300W
MOQ :
1
Delivery Time :
About one week to one month
Overall dimensions of the machine :
331×271×320mm
Payment Terms :
T/T
Large box size :
420×360×420(1Table)mm
Capacity :
14L
Gross Weight :
10.5KG
Supply Ability :
One unit, with a weight of 10,5 kilograms.
Name :
Ultrasonic Auto Parts Cleaner
Price :
￥1350
Model :
JPS-50AL
Packaging Details :
Packaging: Carton Machine dimensions:330×270×320 mm
Cleaning tank size :
300×245×200mm
Certification :
CE, FCC, ROHS, etc.
Place of Origin :
Dongguan, Guangdong
Ultrasonic power :
120～300W
Description

14L [Industrial Equipment] Digital Frequency Conversion Temperature Control Ultrasonic Cleaning Machine For Auto Parts/Medical Devices - Manufacturer Direct


14L Industrial-grade Capacity and Structural Design

High-efficiency Processing Capability: The inner tank measures 300×240×200mm, enabling the following single-batch cleaning capacities:

  • Automotive Parts: 20-30 bearings or 50-80 screws and nuts.
  • Medical Devices: 15-20 surgical instruments plus 10 biopsy forceps. It is suitable for continuous operation on small to medium - scale production lines (with a daily processing capacity of ≥20 batches).

Corrosion-resistant and Durable Materials:

  • Inner Tank: Constructed from one-piece 304 stainless steel (3mm thick). The welds undergo X-ray flaw detection and helium mass spectrometry leak detection (with a leakage rate ≤0.05mbar・L/s). It is resistant to acids and alkalis within a pH range of 2-13, supporting highly corrosive reagents such as sodium hydroxide and alcohol.
  • Outer Shell: Made of cold-rolled steel plate with electrostatic spraying (hardness ≥3H), it resists dust and moisture in industrial environments. Four sets of adjustable shock-absorbing foot pads are installed at the bottom (with a leveling accuracy of ±1mm).

3. Intelligent Industrial-level Operation

7-inch Industrial Touchscreen: Three professional modes are preset: "Automotive Parts Degreasing", "Medical Device Precision Cleaning", and "Mold Release Agent Removal". Parameters can be called up with a single click (for example, when cleaning automotive piston rings, set 28KHz, 70% power, and 65°C to remove carbon deposits within 15 minutes). It supports the storage of 50 custom cleaning recipes, adapting to the cleaning processes of different workpieces.

Intelligent Safety Protection:

  • Low Liquid Level Auto-Shutdown:Real-time liquid level sensor triggers power cut within < 1 second once the tank lacks liquid, effectively protecting transducers from burnout caused by dry running.
  • Overload & Overheat Dual Protection:The power supply cuts off within 0.3 seconds when the input current exceeds 115% of the rated load. Built-in temperature sensors continuously monitor liquid temperature inside the tank; an alarm will be triggered when the temperature exceeds 85°C.
Digital Power Adjustment Series






Model Capacity Ultrasonic power Heating power Cleaning tank size Overall dimensions of the machine Gross Weight Large box size
L W W (LⅹwⅹH)mm (LⅹwⅹH)mm KG (LⅹwⅹH)mm
JPS-20AL 3L 50～120 100 240x135x100 270x170x210 4.1 410×355×345(2Table)
JPS-30AL 6L 70～180 300 300x150x150 330x180x270 6.3 555×435×390(2Table)
JPS-40AL 10L 100～240 300 300x240x150 330x270x270 8.5 735×435×380(2Table)
JPS-50AL 14L 120～300 300 300×240×200 330×270×320 10.5 420×360×420(1Table)
JPS-60AL 15L 150～360 300 330×300×150 360×330×270 10.5 450×420×370(1Table)
JPS-70AL 19L 170～420 300 330×300×200 360×330×320 12.0 460×420×420(1Table)
JPS-80AL 22L 200～480 600 500×300×150 550×330×270 14.0 625×420×370(1Table)
JPS-100AL 30L 240～600 600 500×300×200 550×330×320 16.0 625×420×420(1Table)
