35Khz Ultrasonic sewing machine with rotary horn for fabric sewing

Parameter

Description

Ultrasonic sewing machines are playing an ever increasing role in a wide variety of industries and now also play an important part of garment construction and development, especially in PPE, face masks, non woven gowns, sportswear.

Ultrasonic' s can be used for a wide variety of man made fabrics and plastics, with natural fabrics also being able to be used with a minimum content of at least 60% thermoplastic.

Materials used widely for sealing and cutting filter bags, waterproof covers etc as there is no needle perforation.

Gives beautiful smooth seams to lightweight lingerie and sportswear fabrics and also great for joining to Velcro and polyester straps.

With fabric joins that can be made totally flat against the body, with a bonded tape on to, can be up to 4 x stronger than a sewn seam.

This 35khz roller ultrasonic machine is driven by a rotating horn and a patterned top roller. With both top and bottom Rollers being mounted vertically, this gives a positive narrow width drive for a perfectly flat finish.

35khz output power unit with no ultrasonic sound because of the higher frequency.

The top roller can be changed to different emboss/cut patterns or for cutting and joining fabrics. Replacing traditional needles and threads, it also eliminates the associated problems with the needles puncturing the fabric to sew. This is especially good for PPE, non woven gowns and safety equipment and means the seams don't have to be over taped.

High tech horn & roller treatment process gives tooling a long life and a Marked Increase in quality and productivity.

Ideal for cutting and simultaneously joining two fabric layers to be opened to create flat seams and over taped

Advantages

Our machines offer considerable advantages in many applications, for example through the roll seam method – also individual designed special machines are part of our product portfolio! If you have any questions feel free to contact us or one of our partners. We also create welding samples for you also from your material.

• Fast and cost-effective weaving;

• Resilient seams;

• No need for consumables such as tape, clips or glue;

• Constant results;

• No cooling times and reduced maintenance costs;

• No shooting time for the stapler tool;

• Edging in one operation

• No need for needles, thread, spools and any activities related to color matching, inventories, winding and trimming;

• Evironmentally-friendly because it does not need any adhesives and solvents;

• Edges get sealed without leaving any stitch holes, thus preventing penetration from chemical agents, bloodborne pathogens and other particles.

​

​
