New sharp blade Ultrasonic cutting assembly in mount Ultra-Cutter Systems

Descripersion:

Ultrasonic cutting equipment can be mounted on robot and machine for high-speed ultrasonic cutting, trimming, deburring and chamfering applications. This technology replaces waterjet, laser cutting, hard tooling and manual trimming or routing methods. Whatever your current approach, EcoTrim ultrasonic technology can reduce operating costs and improve trim quality.

Ultrasonic Cutting equipments cleaner cuts and enhanced precision for applications formerly delegated to waterjet, laser cutting, hard tooling and manual trimming. This environmentally-friendly solution reduces operating costs, works within a small footprint, and is energy efficient, clean and eco-friendly.

The high speed and low cutting forces make ultrasonic cutting ideal for non-metallic materials including plastics, foam, carpet, rubber, fiberglass-reinforced plastic and non-woven material.

• Environment-friendly (No noise, no smoke, no air contamination)
• Smooth cutting of difficult-to-cut materials
• Small hand-held size(can be attached to automotive machinery arms)
• No special installation equipmen

This Ultrasonic Cutter is designed compact and lightweight with an easy hand grip to reduce fatigue allowing for long continuous operation. This ideal NSK handpiece offers excellent maneuverability with no vibration to the hand ensuring an accurate and sharp cutting finish. The controller automatically adjusts the output power depending on the load so there is no need to make any adjustments on the controller during the working process. A constant frequency provides steady cutting results. From simple work to fine cutting and complicated shapes, this Ultrasonic cutting Knife performs effortlessly and beautifully.

Ultrasonic Cutters are small in size and do not require large installation areas. Special equipment is not required for the installation. Ultrasonic Cutters are small enough to be hand-held for many operations.
Ultrasonic Cutters can also be attached to automated machinery arms. Although they may not be familiar to you, they play an active role in the manufacturing processes of various industrial products which we use daily.cutt-welding of thermoplastic or thermoplastic coated fabrics and fleeces. Thereby two layers one obove the other are cut and the edges are welded together at the same time.

An even more compact and powerful high frequency ultrasonic cutter than previous models results in a sharper cut. User-friendly design fully utilizes the robot’s operation area. A forced cooling system with air inlet enables extended continuous use.

Assambled on the robotic cells are based on polyarticulated robots using a high frequency generator, or a simple blade.
Machines with one or several robots (STAUBLI, ABB…) according to the production volumes requested (can be used non-stop in 3 shifts).

Oscillator with maximum power output of 500 W enables powerful cutting of difficult-to-cut and extra-tough materials. Signals for on/off, emergency stop, change of output level, and other features can perform with automated machinery or industrial robots.

• High-power ultrasonic cutter with maximum power output of 500 W is compatible with materials needing high-power cutting
• Takes carbide and large blades
• Mountable on automated machinery and industrial robots

Parameter:

Target Materials
Resin plate
Glass fiber (GFRP)
Formed decorative film
Foam
Blow-molded parts
Injection-molded parts
Carbon fiber (CFRP)
Aluminum foil composites
Non-woven fabrics
Controlled-depth kiss cutting
