Specifications
Brand Name :
FUNSONIC
Model Number :
FSC-CR40-82
Certification :
CE
Place of Origin :
China
MOQ :
1 UNIT
Price :
Negotation
Payment Terms :
T/T, Western Union
Supply Ability :
1000 unit per month
Delivery Time :
5-8 work days
Packaging Details :
Packed by Wooden Case
Name :
40Khz Ultrasonic Fabric Cutter
Frequency :
40Khz
Power :
800w
Cutting Thickness :
m(according to Materials)
Cutter Materials :
Steel
Application :
Rubber Cutter
Description

Ultrasonic Cutting Of Thermoplastic Resin Board

Description:

Ultrasonic cutting of thermoplastic resin board uses the energy of ultrasonic waves to melt the local heating of thermoplastic resin board, thereby achieving the purpose of cutting materials. Due to the ultrasonic vibration of the cutting blade, the frictional resistance is very low, and the cutting material is not easily adhered to the blade. It is particularly suitable for cutting viscous and elastic materials, frozen materials (such as food, rubber, etc.), or objects that are not easily pressurized.

Parameters:

Model FSC-CR40-82
Name

40Khz Ultrasonic Rubber Cutter
Frequency 40Khz
Power 800w
Input Voltage 220V±10%,50/60Hz
Cutter Materials Alloy Steel
Width of Blade 82mm(can be customized)
Application Rubber, Plastic Cutter

Common Problems with traditional cutting :

1. Need sharp blades, increase the requirements for blades;

2. Cutting cloth cannot seal the edges, as cutting edges can easily cause edge breakage and damage;

3. Sticky objects are difficult to cut and easily stick to knives, affecting cutting effectiveness and efficiency;

4. When cutting, pressure needs to be applied to the object, which can easily deform soft or fragile food;

When cutting certain items, a large amount of particles and fragments will be generated, increasing waste.

Ultrasonic Cutting Of Thermoplastic Resin Board
