Advanced Ultrasonic Spray Coating Machine with Low Power Ultrasound Spray Nozzle 20-200KHz Frequency and 15-45μm Particle Size
Advanced Ultrasonic Spray Coating Machine with Low Power Ultrasound Spray Nozzle 20-200KHz Frequency and 15-45μm Particle Size
Advanced Ultrasonic Spray Coating Machine with Low Power Ultrasound Spray Nozzle 20-200KHz Frequency and 15-45μm Particle Size
Advanced Ultrasonic Spray Coating Machine with Low Power Ultrasound Spray Nozzle 20-200KHz Frequency and 15-45μm Particle Size
Advanced Ultrasonic Spray Coating Machine with Low Power Ultrasound Spray Nozzle 20-200KHz Frequency and 15-45μm Particle Size
Advanced Ultrasonic Spray Coating Machine with Low Power Ultrasound Spray Nozzle 20-200KHz Frequency and 15-45μm Particle Size
Advanced Ultrasonic Spray Coating Machine with Low Power Ultrasound Spray Nozzle 20-200KHz Frequency and 15-45μm Particle Size
Advanced Ultrasonic Spray Coating Machine with Low Power Ultrasound Spray Nozzle 20-200KHz Frequency and 15-45μm Particle Size
Specifications
Brand Name :
FUNSONIC
Model Number :
FS150
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 UNIT
Price :
Negotation
Payment Terms :
T/T,Western Union
Supply Ability :
1000 unit per month
Packaging Details :
Packed by Wooden Case
Production Name :
Ultrasonic Precision Spray Coated Machine
Frequency :
20-200Khz for optional
Power :
1-15w
Automized Particle Size Range :
15-20μm
Spray flow :
0.01-50ml/min
Liquid viscosity :
<30cps
Particle size :
<8μm
Application :
Suitable for Qualitative Experiments
Description

Advanced Ultrasonic Spray Coating FS150 with Low Power Ultrasound Spray Nozzle



Description:


Ultrasonic spraying equipment is an advanced spraying technology that uses high-frequency vibration of ultrasound to atomize liquid, and uniformly sprays the atomized liquid onto the target surface through a nozzle. It is widely used in the spraying process of coatings, inks, cleaning agents, etc.



Parameters:


Product Type Ultrasonic Precision Spraying Coated Machine Laboratory Desktop Type FS150
Spray Nozzle Operating Frequency 20-200KHz
Nozzle Power 1-15W
Continuous Spraying Volume Max 0.01-50ml/min
Effective Spraying Width 2-100mm
Spray Uniformity ≥95%
Solution Conversion Rate ≥95%
Dry Film Thickness 20nm-100μm
Solution Viscosity ≤30cps
Temperature Range 1-60℃
Atomized Particles (Median Value) 10-45μm (distilled water), determined by the frequency of the nozzle
Diversion Pressure Max ≤0.10MPA
Input Voltage 220V±10%/50-60Hz
Exercise Mode X. Y-axis and Z-axis linear track motion module, performing up and down/front and back/left and right movements
Motion controller Operating software system, parameter settings
Control Content Ultrasonic spraying, liquid supply, heating, ultrasonic dispersion and other systems
Liquid Supply Method Precision injection pump
Ultrasonic Dispersion System (Optional) 50ml, 40K, biological grade sampler
Rated Power of Ultrasonic Dispersion System 200W,10A



Advantages of Using Ultrasonic Spray System in Antibacterial and Antiviral Coatings :


1. High speed spraying: The ultrasonic spraying system can spray liquid particles onto the surface of the object at high speed, effectively covering the entire surface and ensuring uniform distribution of the coating.

2. Fine granulation: Ultrasonic waves can refine liquids into tiny particles, increasing the contact area between the coating and the target surface, and improving the adhesion and uniformity of the coating.

3. Low temperature treatment: Ultrasonic spraying system does not require high temperature, so it can avoid material damage and deformation, and is suitable for various substrates.

4. Efficient sterilization: Due to the small and evenly distributed coating particles, the antibacterial and antiviral effects are significant, which can effectively kill bacteria and viruses and reduce the risk of cross infection.
