Specifications
Brand Name :
QRsonic
Model Number :
QR-1070-2BZ-BJ
Certification :
CE
Place of Origin :
China
MOQ :
1 pcs
Price :
Negotation
Payment Terms :
T/T, Western Union
Supply Ability :
2000pcs per month
Delivery Time :
3 workdays
Packaging Details :
Packed in carton
Products Name :
Ultrasonic Oscillator
Output Power :
100w
Frequency :
70khz
Ceramic disc Diameter :
10mm
Qty of ceramic discs :
2pcs
Capacitance :
0.7-0.8nf
Description

70Khz Ultrasonic Vibration with Titanium Horn for Smart Card Wire Welding

Description:

The ultrasonic Oscillator is also called the ultrasonic vibrator. The whole of the industry is connected to the horn and the horn is called a vibrator. The ultrasonic vibrator is a device that converts electrical energy and mechanical energy (acoustic vibration) by piezoelectric effect of piezoelectric ceramics, and amplifies the front and rear radiation cover blocks by acoustic impedance matching.

Specifications:

Model QR-1070-2BZ-BJ
Frequency 70khz
Output power 100 watt
Ceramic disc Diameter 10mm
Qty of ceramic discs 2pcs
Capacitance 0.7-0.85nf
Application Ultrasonic Card Embedding Machine

Competitive Advantage of 70Khz Ultrasonic Oscillator:

· The amplitude can be adjusted to ensure the RFID embedding stability;

· High frequency, reach to 70khz, welding more smoothly;

· Ultrasonic system design precision is very high, good customer feedback;

· In particular, digital power supply design, has been in a leading position in the ultrasonic industry;

· Automatically tracks frequency and has a very wide frequency range that extends the life of the ultrasonic units.

· Cabinet type, can control 3/4/5 burying heads to work at the same time

· touch screen control or external PLC control, easier operation

· 20%-100% energy continuously adjustable on the line, used in all sizes of smart card embedding applications

· wear-resistant titanium alloy tool head, suitable for 0.05-0.2 mm copper wire

· light body design, beautiful and durable, good heat dissipation

· 24-hour work, uniform energy output

· Suitable for high-speed embedding applications, embedding twice the speed of 60K devices
