Anticorrosive Liquid Thermal Gap Filler Heatproof Anti Seismic
Anticorrosive Liquid Thermal Gap Filler Heatproof Anti Seismic
Anticorrosive Liquid Thermal Gap Filler Heatproof Anti Seismic
Anticorrosive Liquid Thermal Gap Filler Heatproof Anti Seismic
Specifications
Brand Name :
AOK
Model Number :
TM300
Certification :
RoHS, Reach, UL
Place of Origin :
China
MOQ :
400 ml (200 ml each part)
Payment Terms :
T/T
Delivery Time :
13-15 working days
Packaging Details :
50 ml(25 ml each part)/ 400 ml (200 ml each part)/ 20 kg(10 kg each part)
Product Name :
TM300 Single Part 3w Thermal Conductivity Gap Filler With Ceramic Filler And Silicone
Composition :
Ceramic filler + Silicone
Thermal conductivity :
3.0 W/m.K
Usage Temperature :
-40 ℃ ~ 150 ℃
Thermal Resistance :
0.3 (℃-in2/W)0.1mm@50psi
Flammability :
V-0
Description
Attribute Value Test Method
Composition Ceramic filler + Silicone -
Color Green Visual
Density(g/cc) 2.9 ASTM D792
Extrudability(g/s) 5.0 ISO9048
Usage Temperature(℃) -40~150 --
Electrical
Breakdown Voltage(kv/mm) ≥5.0 ASTM D149
Dielectric Constant(@10mhz) 7.3 ASTM D150
Volume Resistivity(Ω.cm) 1.0*1014 ASTM D257
Flammability V-0 UL94
Thermal
Thermal conductivity(W/m.K) 3.0 ASTM D5470

Product feature
■ Thermal conductivity: 1.0-6.0 W/m.K
■ No cure required
■ Highly compliant
■ Low pressure vs. deflection
■ High volume applications

Typical applications
■ Networking and Telecommunications
■ Consumer Electronics: Gaming Systems, LCD TVs, Displays
■ IT: Notebooks, Tablets, Memory Modules
■ Industrial: LEDs, Power Supplies
■ Automotive: Control Modules, Turbo Actuators

Purchasing information
Packing specification: 300 ml Cartridge/1kg Jar/20kg Pail

Directions for use
• Stir prior to use
• Application surface should be clean and free of dust, dirt or oils.
• When using material from jar or pail, the container should be sealed and closed immediately after usage to prevent foreign material contamination.
• Follow storage instruction for unused material.
• Application bond line should not exceed 6mm.
• Avoid contact with the eyes.
• Product is nontoxic

Storage & Shelf life

Store in a cool, dry, well-ventilated place. Shelf life of the product is 6 months after date of shipment.
