0.1mm 0.2mm 0.3mm 0.4mm Fiw Wire High Voltage Enameled Copper Solderable
0.1mm 0.2mm 0.3mm 0.4mm Fiw Wire High Voltage Enameled Copper Solderable
Specifications
Brand Name :
Ruiyuan
Model Number :
FIW
Certification :
UL/ISO9001/ISO14001/RoHS/Reach
Place of Origin :
China
MOQ :
20Kilogram/Kilograms
Price :
Negotiation
Payment Terms :
Negotiation
Supply Ability :
100Ton/week
Delivery Time :
2-15 days
Packaging Details :
Carton
Product name :
0.1mm 0.2mm 0.3mm 0.4mm High voltage enameled copper wire FIW
Material :
Copper
Size :
0.1mm-0.4mm
Insulation :
UEW
Thermal rating :
180
Key word :
0.1mm 0.2mm 0.3mm 0.4mm High voltage enameled copper wire FIW
Description

0.1mm 0.2mm 0.3mm 0.4mm High voltage enameled copper wire FIW

Alternative to TIW wire

Rvyuan FIW wire can be a substitute for TIW wire when they are applied to switching power transformers. As there are a huge range of selection of overall diameters for FIW wire, costs can be reduced. Meanwhile, it has better windability and solderability compared to TIW wire.

Name 0.1mm 0.2mm 0.3mm 0.4mm High voltage enameled copper wire FIW
Key word 0.1mm 0.2mm 0.3mm 0.4mm High voltage enameled copper wire FIW
Insulationh Enamel
Thermal rating 180
Diameter of the enameled copper wire 0.04mm-0.4mm
Type 0.1mm 0.2mm 0.3mm 0.4mm High voltage enameled copper wire FIW

Nom.Diameter(mm)
Min. Breakdown voltage (V)
Grade ofFIW3
Grade ofFIW4
Grade ofFIW5
Grade ofFIW6
0.040
1458
2349
3159
3969
0.050
1782
2673
3564
4455
0.060
2025
3159
4212
5265
0.071
2187
3159
4212
5265
0.080
2268
3402
4536
5670
0.090
2430
3564
4698
5832
0.100
2592
3888
5184
6480
0.120
2888
4256
5624
6992
0.140
3116
4636
6156
7676
0.160
3420
5092
6764
8436
0.180
3724
5548
7372
9196
0.200
3952
5852
7752
9652
0.250
4712
6992
9272
11552
0.300
5244
7600
9956
12312
0.400
5460
7630
9800
11970

0.1mm 0.2mm 0.3mm 0.4mm Fiw Wire High Voltage Enameled Copper Solderable0.1mm 0.2mm 0.3mm 0.4mm Fiw Wire High Voltage Enameled Copper Solderable​
