Autonomous Obstacle Avoidanc Agricultural Spraying Drone,Waterproof 5 level Resistance 15L Payload with 6 Smart Nozzles
Autonomous Obstacle Avoidanc Agricultural Spraying Drone,Waterproof 5 level Resistance 15L Payload with 6 Smart Nozzles
Autonomous Obstacle Avoidanc Agricultural Spraying Drone,Waterproof 5 level Resistance 15L Payload with 6 Smart Nozzles
Autonomous Obstacle Avoidanc Agricultural Spraying Drone,Waterproof 5 level Resistance 15L Payload with 6 Smart Nozzles
Autonomous Obstacle Avoidanc Agricultural Spraying Drone,Waterproof 5 level Resistance 15L Payload with 6 Smart Nozzles
Autonomous Obstacle Avoidanc Agricultural Spraying Drone,Waterproof 5 level Resistance 15L Payload with 6 Smart Nozzles
Autonomous Obstacle Avoidanc Agricultural Spraying Drone,Waterproof 5 level Resistance 15L Payload with 6 Smart Nozzles
Autonomous Obstacle Avoidanc Agricultural Spraying Drone,Waterproof 5 level Resistance 15L Payload with 6 Smart Nozzles
Specifications
Place of Origin :
China
Brand Name :
GL
Certification :
CE
Model Number :
GLF
MOQ :
1
Price :
Customized
Packaging Details :
Aluminum Hard Case
Delivery Time :
5days
Payment Terms :
TT
Supply Ability :
800SETS/WEEK
Protection Level :
IP67
Type :
Outlet Box
Weight :
16kg
Battery capacity :
16000mAh
Flying time :
25mins
External Size :
1650*1650*720mm
Max Take Off Weight :
45Kg
Radar :
Autonomous Obstacle Avoidance
Description
Autonomous Agricultural Spraying Drone,Waterproof and Weather 5 level Resistance 15L Payload with 6 Smart Nozzles Autonomous Obstacle Avoidance
Specifications Details:
Class Professional Industrial Class
Take Off Weight Standard: 35KG
MTW: 45KG
Hover Accuracy Hover Time: 25min(16000MA,TW 20KG)
11min(16000ma TW 35KG)
Tested by Sea Level;Wind Speed <3m/s
Flight Speed Max Working Flight Speed:8m/s
Max Flight Speed:12m/s
Flight Height ASL 3000m
Wheelbase 1650mm
Recharger 12S Dual 20A
Recharging Voltage;44V
Rated Power:1000W
Battery Power Battery:12S16000ma
Power Flight
Rated Power:7920W
Hover Power :3960W
RC
Working Power:9W
Body Parameter
Dimension Arm length:580mm
External Size:1650*1650*720mm,(Arms Spread without Propellers)
680*680*720mm(Fold Size)
Weight Complete Body:16KG (Without Battery)
Ambient Flight Advised Temperature:0C-40C
RC Working Temperature:-10C-40C
Storage Temp:Less than 3months,-20C—45C
More than 3months:22C—28C
Recharging Temp:0C—40C
Spray System Spray System
Tank Capacity:15L
Working Payload:15KG
Nozzle:110Angle 001 Fan Nozzle,Flow:0.379L/min
Advise:Nozzle110Angle 015 Fan Nozzle Flow:0.525L/min
Numbers:6
Max Spray Rate:Each110Angle 001 Fan Nozzle 0.43L/min
Atomizing Particle Size:110Angle001 Fan Nozzle:130-250um
Dynamical System Motor
Stator Size:83*20mm
KV:120rpm/V
Pull:11..8KG/rotor
Rated Power :1320W
Weight:780g
ESC
Max Working Current:(Continous )100A
Working Voltage:50..4V
Compatible Signal Frequency:621HZ
Propeller:30inch
Material:Carbon Fiber
Dimension:30*10.5inch
Weight:110g

Autonomous Obstacle Avoidanc Agricultural Spraying Drone,Waterproof 5 level Resistance 15L Payload with 6 Smart Nozzles

Autonomous Obstacle Avoidanc Agricultural Spraying Drone,Waterproof 5 level Resistance 15L Payload with 6 Smart Nozzles

Video Link:
https://youtu.be/AvFWzTJIDQU
https://youtu.be/k_d2uh4ROIw (Flight In South America)
