400MHz-5800MHz 50W Power Amp Signal Jammer Module With Temp Protection
400MHz-5800MHz 50W Power Amp Signal Jammer Module With Temp Protection
400MHz-5800MHz 50W Power Amp Signal Jammer Module With Temp Protection
400MHz-5800MHz 50W Power Amp Signal Jammer Module With Temp Protection
400MHz-5800MHz 50W Power Amp Signal Jammer Module With Temp Protection
400MHz-5800MHz 50W Power Amp Signal Jammer Module With Temp Protection
400MHz-5800MHz 50W Power Amp Signal Jammer Module With Temp Protection
400MHz-5800MHz 50W Power Amp Signal Jammer Module With Temp Protection
400MHz-5800MHz 50W Power Amp Signal Jammer Module With Temp Protection
400MHz-5800MHz 50W Power Amp Signal Jammer Module With Temp Protection
400MHz-5800MHz 50W Power Amp Signal Jammer Module With Temp Protection
400MHz-5800MHz 50W Power Amp Signal Jammer Module With Temp Protection
Specifications
Place of Origin :
Guangdong, China
Brand Name :
flysafe
Price :
Negotiable
MOQ :
1
Delivery Time :
5-8work days
Payment Terms :
LC,T/T,MoneyGram,Western Union,D/P,D/A,L/C
Frequency :
400-5800MHZ(Customized)
Size :
179*50*20mm
Weight :
294g
Description
400-5800MHz 50W Power Amp Signal Jammer Module With Temp Protection

Product Description

This is a 400-5800MHz 50W amplifier module with temperature protection. This high performance 400-5800MHz 50W amplifier module is a cutting edge solution for enhancing signal strength in a variety of applications. The temperature protected 400-5800MHz 50W amplifier module has a frequency range of 400MHz to 5800MHz and is suitable for use in a variety of communication systems such as schools, broadcasting, and prisons. The amplifier module features a compact and lightweight design for easy installation and integration into a variety of systems.

Product Paramenters

NO
Item
Data
Unit
Notes
1
Frequency
400-5800
MHZ
Customized
2
Work Temperature
-20~+70
℃
3
Max Output Power
50
W
4
Work Voltage
DC28
V
5
Max Gain
47
dB
6
Flatness
±1
dB
7
Max Current
4
A
8
Output VSWR
≤1.5

9
Output Connector
SMA/F 50Ω
Customized
10
Power Amplifier Efficiency
45
when Max Output
11
Switch Control
high low
level current
V
0V off /0.6 on
12
Standing Wave Protection
OK

13
Temperature Protection
75°
℃
14
Size
179*50*20
mm
15
Weight
0.294
Kg

Details Images

400MHz-5800MHz 50W Power Amp Signal Jammer Module With Temp Protection
400MHz-5800MHz 50W Power Amp Signal Jammer Module With Temp Protection
400MHz-5800MHz 50W Power Amp Signal Jammer Module With Temp Protection
