500rpm Twin Screw Polymer Devolatilization Extruder for Rubber Processing
500rpm Twin Screw Polymer Devolatilization Extruder for Rubber Processing
Specifications
Packaging Details :
Wooden Base Plate, Damp Proof Plastic Lining
Application :
Rubber, Chemical Engineering,Food And Pharmacy
Place of Origin :
SiChuan, China
Price :
USD 270000-1500000
Certification :
ISO9001
MOQ :
1
Usage :
Devolatilization,Latex Coagulation,Dewatering,Mixing And Reactive Extrusion
Warranty :
1 Years
Plastic Processed :
Rubber
Supply Ability :
100 sets per year
Brand Name :
ADVS
Payment Terms :
T/T
Screw Design :
Double Screw
Highlight :
devolatilization extruder, twin screw compounding extruder
Model Number :
YSE65
Description
Product Overview

The YSE series counter-rotating twin screw extruders are professionally developed for polymer devolatilization and reactive extrusion processes. This equipment is widely applied in chemical, food and pharmaceutical industries, supporting multiple complex production processes including polymer devolatilization, latex coagulation, material dewatering, homogeneous mixing and reactive extrusion. It is especially suitable for high-viscosity material reactive extrusion and high-efficiency devolatilization production.

Technical Parameters
Item Specification
Model YSE65/80-500
Screw Diameter 50mm / 65mm (Intermeshing & Non-intermeshing optional)
L/D Ratio 80:1
Max Screw Speed 500rpm
Motor Power 132kW
Air Vent Quantity 3 sets
Liquid Injection Vent 9 sets
Gas Feeding Vent 3 sets
Barrel Structure Fully openable design
Core Product Advantages
1. High Torque Design

Equipped with high-torque transmission structure, the extruder stably handles various high-viscosity polymer materials. It maintains stable extrusion status under high-load operation and fully meets high-yield and high-efficiency production requirements.

2. Ultra-long Service Life

The matched high-precision gearbox adopts optimized transmission structure and high-quality accessories, with a designed service life of more than 72,000 working hours (equivalent to 10 years of stable operation), reducing equipment maintenance and replacement costs.

3. Super Long L/D Ratio

Adopting 80:1 ultra-long L/D ratio design, it reserves sufficient installation space for multiple vents and feeding hoppers. It is highly suitable for high-standard polymer devolatilization processes and supports diverse reactive extrusion to realize uniform mixing and full reaction of different materials.

4. Flexible Customized Structure

Two screw structure modes are optional: intermeshing and non-intermeshing. Customized design can be carried out according to customer’s material characteristics and production processes to match different devolatilization and reactive extrusion production demands.

Main Application Fields

Ideal for high-viscosity material processing, polymer devolatilization, reactive extrusion, latex coagulation and dewatering, widely used in chemical engineering, food processing and pharmaceutical industries.
