| Panel Brand | AUO | Panel Model | T650QVR05.6 CELL |
| Panel Size | 65 inches | Panel Type | a-Si TFT-LCD, Liquid Crystal Glass, FOB |
| Resolution | 3840(RGB)×2160, UHD, 68PPI | Pixel Arrangement | RGB Vertical Stripe |
| Display Area | 1428.48(W)×803.52(H) mm | Dimensions | 1440.78(W)×818.22(H)×1.32(D) mm |
| Viewable Area | - | Surface Treatment | Hard coating (2H) |
| Panel Brightness | 0 cd/m² | Contrast Ratio | 4000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Operation Mode | AMVA3, Normally Black, Transmissive |
| Viewing Direction | Full View Angle | Response Time | 8 (Typ.)(G to G) ms |
| Substrate Thickness | 0.50+0.50 mm | Transmittance | 4.8% (Typ.)(Including Polarizer) |
| Display Color | 1.07B, 72% NTSC | Backlight Type | No Backlight |
| Operating Frequency | 60Hz | Touch Screen | No Touch |
| Panel Weight | 3.61Kgs (Typ.) | Panel Application | [Icon] |
| Driver IC | COF Bonded with 16 source chips | | |
| Signal Interface | V-by-One 8 lane, 51 pins, Terminal | | |
| Driving Voltage | 12.0V (Typ.) | | |
| Operating Environment | Operating: 0 ~ 50 °C ; Storage: -20 ~ 60 °C | | |
