Medical Grade All In One FHD Endoscope Camera & Recorder System For ENT, Laparoscopy And Rigid Endoscopy
Medical Grade All In One FHD Endoscope Camera & Recorder System For ENT, Laparoscopy And Rigid Endoscopy
Medical Grade All In One FHD Endoscope Camera & Recorder System For ENT, Laparoscopy And Rigid Endoscopy
Medical Grade All In One FHD Endoscope Camera & Recorder System For ENT, Laparoscopy And Rigid Endoscopy
Medical Grade All In One FHD Endoscope Camera & Recorder System For ENT, Laparoscopy And Rigid Endoscopy
Medical Grade All In One FHD Endoscope Camera & Recorder System For ENT, Laparoscopy And Rigid Endoscopy
Medical Grade All In One FHD Endoscope Camera & Recorder System For ENT, Laparoscopy And Rigid Endoscopy
Medical Grade All In One FHD Endoscope Camera & Recorder System For ENT, Laparoscopy And Rigid Endoscopy
Medical Grade All In One FHD Endoscope Camera & Recorder System For ENT, Laparoscopy And Rigid Endoscopy
Medical Grade All In One FHD Endoscope Camera & Recorder System For ENT, Laparoscopy And Rigid Endoscopy
Specifications
Brand Name :
TUYOU
Model Number :
TU-24LSD1B
Certification :
CE/ISO13485/FDA
Place of Origin :
Guangdong, China
MOQ :
1 set
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
1000 Unit/Units per Month TUYOU Portable HD All in one ENT Camera Endoscopy Light Source
Delivery Time :
7-14 work days
Packaging Details :
TUYOU Portable HD All in one ENT Camera Endoscopy Light Source Endoscope Camera System
Standard carton with foam
1 Set/Carton Box
After-sale Service :
Online technical support
Image Sensor :
1/2.8" SONY CMOS, 1/1.8" SONY CMOS
Warranty :
2 years
Instrument classification :
Class I
Product name :
HD Endoscopy Camera System
Type :
Endoscope
Properties :
Surgical Laparoscope Endoscopy Urology Arthroscope
Input Interface :
SDI 60FPS
SNR :
45 dB
Description
Medical Grade All In One FHD Endoscope Camera & Recorder System For ENT, Laparoscopy And Rigid Endoscopy
Products Description

Medical - grade 24 - inch 1080P FHD display with SDI 60fps input and multi - output interfaces (HDMI/SDI/DVI/VGA/CVBS) for external monitor connection.

Built - in LED light source (100W effective optical power, 4500–6500K color temperature, 2600lm brightness, 30,000 - hour service life).

SONY CMOS sensor - equipped handle camera with FHD resolution (1920x1080 pixels), supporting FREEZE, AWB (Auto White Balance), 0–8x digital zoom, and 1–30 steps of brightness adjustment.

Customizable camera head compatible with multiple lens modes (PETD/Fiber/Arthroscope/Cystoscope/Hysteroscope/Laparoscope/ENT, etc.) and multi - language support (Chinese, English, Japanese, Korean, etc.).

Device specs: L336×W330×H116mm, 4.2KG; Power supply: AC110V~240V.

24 - inch display as standard (other sizes available on request).

Medical Grade All In One FHD Endoscope Camera & Recorder System For ENT, Laparoscopy And Rigid Endoscopy

Endoscope System

Parameter Specification
Input Interface 1080P
Output Interface HDMI / SDI / DVI / VGA / CVBS
Power Supply AC 110V~240V
Shortcut Key Functions Freeze / White Balance / Digital Zoom
SNR (Signal Noise Ratio) <45dB
Operating Temperature Range 0°C~40°C
Dimensions (L×W×H) 336 × 330 × 116 mm
Weight 4.3 kg


Handle Camera

Parameter Specification
Image Sensor SONY CMOS
Resolution 1080P (1920×1080 pixels)
Digital Zoom 0-8X magnification
Functions Freeze / AWB (Auto White Balance) / Zoom in-out
Waterproof Rating IP67 (Fully dustproof and waterproof against temporary immersion)
Cable Length 3 meters (9.8 feet)


Medical Grade All In One FHD Endoscope Camera & Recorder System For ENT, Laparoscopy And Rigid Endoscopy

Medical Grade All In One FHD Endoscope Camera & Recorder System For ENT, Laparoscopy And Rigid Endoscopy
Medical Grade All In One FHD Endoscope Camera & Recorder System For ENT, Laparoscopy And Rigid Endoscopy

Manufacturer High Quality 24'' FHD All-in-one Camera System For Laparoscopy Plastic ENT Surgery

FAQ
Q: Are you a factory or a trading company?
A: We are a Chinese medical imaging instruments manufacturer. All the products are made of our workers, we have 4 production lines and R&D team.
Q: Where are you ?
A: Our adress is buliding 3,Yunchuang Valley Southern Pacific, Fenghuang District, Shenzhen City, Guangdong Province, China.You are welcomed to visit our factory.
Q: Can you accept OEM?
A: Yes, we offer "TUYOU" brand to you. But if you need, we can also offer OEM service.
Q: What's your deliver time?
A: It will be delivered within 7 working days upon your payment; Samples are ready-made.
Q: What is the warranty?
A: The free warranty is two years. If there is any fault for our products within the free warranty period, we will repair it and change the fault assembly for free.
Q:What's the payment term?
A.We accept payment by T/T Bank Transfer, Trade Assurance Service, Western Union, Money Gram, Paypal, L/C, Cash etc.
