HCW Extreme Weather Resistance Automatic Barrier Gate with 1.5-3S Adjustable Speed and DC Brushless Motor
HCW Extreme Weather Resistance Automatic Barrier Gate with 1.5-3S Adjustable Speed and DC Brushless Motor
HCW Extreme Weather Resistance Automatic Barrier Gate with 1.5-3S Adjustable Speed and DC Brushless Motor
HCW Extreme Weather Resistance Automatic Barrier Gate with 1.5-3S Adjustable Speed and DC Brushless Motor
HCW Extreme Weather Resistance Automatic Barrier Gate with 1.5-3S Adjustable Speed and DC Brushless Motor
HCW Extreme Weather Resistance Automatic Barrier Gate with 1.5-3S Adjustable Speed and DC Brushless Motor
HCW Extreme Weather Resistance Automatic Barrier Gate with 1.5-3S Adjustable Speed and DC Brushless Motor
HCW Extreme Weather Resistance Automatic Barrier Gate with 1.5-3S Adjustable Speed and DC Brushless Motor
HCW Extreme Weather Resistance Automatic Barrier Gate with 1.5-3S Adjustable Speed and DC Brushless Motor
HCW Extreme Weather Resistance Automatic Barrier Gate with 1.5-3S Adjustable Speed and DC Brushless Motor
Specifications
Brand Name :
HCW
Model Number :
S300
Certification :
CE
Place of Origin :
China
MOQ :
2 piece
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
100 pieces per day
Delivery Time :
5-8 working days
Packaging Details :
wooden case
Brand name :
HCW
Product model :
S300
Chassis material :
Cold rolled plate
Arm length :
1-6 meters
Arm material :
Aluminum/foam
Motor type :
DC Brushless Motor
Speed :
1.5-3S adjustable
Product size :
340*280*1045mm
Safety & Control Features :
Integrated Control Mainboard Dedicated for Parking Barriers
Arm type :
Straight/Folding/Fence/LED Foam/Telescopic arms
Description
HCW Extreme Weather Resistance Automatic Barrier Gate with 1.5-3S Adjustable Speed Boom Barrier
HCW robust parking barrier gate features 1.5-3 second adjustable speed and exceptional tolerance in extreme weather conditions, providing reliable traffic control in high-humidity environments.
Product Overview
The S300 barrier gate is a durable traffic control solution designed for efficient operation. Operating on AC 220V±10% (50Hz), it withstands temperatures from -25℃ to 70℃ and humidity levels of 5%-95%, ensuring reliable performance in harsh conditions. Its bidirectional design allows flexible installation.
Technical Specifications
Brand Name HCW
Product Model S300
Chassis Material Cold Rolled Steel Plate
Boom Length 1-6 meters
Arm Material Aluminum/Foam
Motor Type Brushless DC Motor
Speed 1.5-3S Adjustable
Product Dimensions 340×280×1045mm
Warranty 1 Year
Humidity Range 5% - 95%
Safety & Control Features Anti-collision Rebound/Loop Detection/Infrared
Arm Types Straight/Folding/Fence/LED Foam/Telescopic Arm
Key Features and Benefits
  • Smart Operation: Supports wireless remote control (up/down/stop) and manual button operation, seamlessly integrating into modern access control systems
  • Patented Integrated Core Mechanism: Combines frame, reducer and transmission system to reduce vibration and improve operational precision
  • Adjustable and Safe Arm System: Tension spring system safely adapts to different arm lengths, providing high security and flexibility
  • Durable and Aesthetic Housing: Corona high-temperature powder coating (180°C-250°C) provides corrosion resistance and maintains smooth appearance
  • Multi-layer Safety Protection: Customizable safety system including ground loop, pressure sensors and infrared detectors for 360° protection
Motor and Performance
Equipped with brushless DC motor (80W/120W), this telescopic barrier provides fast 3-second or stable 6-second lifting cycles. The compact yet powerful CW203 telescopic barrier is ideal for parking lots, toll stations, and secure areas.
