Professional Manufacture Straight Arm Barrier Gate with Black Rubber for High Traffic
Professional Manufacture Straight Arm Barrier Gate with Black Rubber for High Traffic
Specifications
Brand Name :
WEJOIN
Model Number :
DZ801
Certification :
CE ISO SGS
Place of Origin :
CHINA
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
10000 sets/month
Delivery Time :
15 working days after payment received
Packaging Details :
carton
Force :
Heavy duty
Motor :
Die Casting Aluminum Alloy
Speed :
1.5s-6s
Power :
180W
Delivery :
15 working days after payment received
Voltage :
AC100-265V
Description

Professional Manufacture Straight Arm Barrier Gate with Black Rubber for High Traffic


Parking Barrier Gate Quick Detail

WEJOIN Mid-Grade DC Barrier Gate WJDZ04VF

DC variable frequency control motor

Higher Stability, Longer Service Life, and Easier Operation


Parking Barrier Gate Application

Suitable for indoor as well as an outdoor parking area
Parking lots, goods yard, railway crossing, commercial premises, apartment block access shopping malls, hospitals, stadiums, business centers, etc.


Parking Barrier Gate Functions & Features

1. DC variable frequency control motor drive, equipped with connecting rod transmission mechanism, balance spring, stable and reliable operation, motor life up to 4.5 million times, spring life 500,000 times.

2. Auto reversing on obstacle function, the boom will auto reverse when it meets obstacle during the closing process.

3. Support external radar, coil, infrared anti-smashing function, built-in DC 12V power output, can be used for external radar power supply.

4. Support RS485 communication or RS485 off-line connection.

5. Optional Bluetooth module, convenient debugging of barriers through small programs.

6. Large LCD screen display, English visual menu, easy function selection and debugging.

7. Left-installation and right-installation can be changed.

8. Speed 1.5~6 seconds can be adjusted.


Parking Barrier Gate Technical Data

Model

 WJDZ04VF (speed 1.5~6s adjustable)
Running Speed 1.5s-6s 6s 6s 6s 6s
Boom-Type Straight 90° Folding 180° Folding 2 Fence 3 Fence
Max Boom Length 3-6m 5m 4m 4.5m 4m
Housing Dimension 336*325*1030MM, 335*285*920MM
Input Voltage AC100-265V
Frequency 50/60HZ
Motor Voltage DC24V
Enclosure Rating IP54
Working Temperature -30℃~ + 70℃
MTBF 4000000 times
Traffic Flow Application 3000 times/ 24 hours
Max Motor Power 180W
Max Motor Speed 500r/min
Max Torque 260N.m
