Die Casting Parking Boom Gate Infrared Photocell RS485 Drop Arm Barrier Gate
Die Casting Parking Boom Gate Infrared Photocell RS485 Drop Arm Barrier Gate
Specifications
Brand Name :
WEJOIN
Model Number :
WJDZ102
Certification :
CE,ISO,
Place of Origin :
China
MOQ :
1 unit
Price :
negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
5000 Units / Month
Delivery Time :
3-7 working days
Packaging Details :
Carton,wooden box
Trade Terms :
EXW,FOB,CIF
Speed :
1S; 1.8S; 3S; 6S
Color :
Orange
Motor Material :
Die-casting Aluminum alloy
Housing Material :
Steel
Max Boom Length :
8 metes
COM Interface :
RS485
Description

Boom Barrier Gate System High-Speed Drop Arm Barrier Gate for Car Parking Management

Parking Barrier Spring selection

The spring is a stretchable one and the specification is as follows:

Spring type Diameter Spring length
Small size 4.5MM 280MM
Medium size 5.5MM 280MM
Big size 6.5MM 280MM

Toll Gate Functions and features

1. Manual advanced clutch, to rise up the boom by hand when power off, it will auto-reset when power on.

2. Adopts the compression spring as a safety precaution to avoid accidents caused by the spring broken.

3. Three buttons to control the boom to rise up or fall or stop.

4. Auto-reversing when meets obstacles.

5. Available for the internal and external loop detector.

6. Opening, closing, and stopping to control the interface.

7. Infrared photocell for anti-bumping.

8. RS485 communicational module to connect the computer.

9. Traffic lights interface.

10. Wire control and remote control.

11. Auto warming up when the system is below zero degrees centigrade.

Barrier Gate Working environment and data

1. Mechanism temperature -25℃+85℃

2. Control board temperature -20+85℃

3. Power supply 220V±10% 50/60 Hz

110V±10% 50/60 Hz

4. Rated power 120W

5. Relative humidity ≤90%

6. Remote control ≥30M

7. Net weight 60 Kg

Die Casting Parking Boom Gate Infrared Photocell RS485 Drop Arm Barrier Gate
