OEM Parking Barrier Gate High Control Precision Road Safety Folding Arm
OEM Parking Barrier Gate High Control Precision Road Safety Folding Arm
Specifications
Brand Name :
WEJOIN
Model Number :
WJDZ04SV
Certification :
CE ISO SGS
Place of Origin :
CHINA
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
10000 sets/month
Delivery Time :
3-5 working days after payment received
Packaging Details :
carton
Motor :
Die Casting Aluminum Alloy
Speed :
3~5s adjustable
Power :
150W
Voltage :
AC220V; AC110V
Application :
parking lot
Warranty :
2 Year
Description

OEM available control road safety folding arm parking boom gate

Parking Barrier Gate Quick Detail

DC Brushless Servo Motor

Higher Stability

Longer Service Life and Easier Operation

Parking Barrier Gate Brief Introduction
This product is highlighted in frequency applications and longer lifetime. This is our newly-produced DC servo barrier gate, which utilizes the updated electronic control technology and machinery processing technology, no limit switch design, to realize non-adjust of mechanism, adjustable speed, automatic speed reduction, ext. In this way, make the barrier operate more steadily and more reliably.

Parking Barrier Gate Packing List

Name Specification Quantity Unit Application
Screw, Nuts, Flat Pad M12*70 2 sets Fixing the boom
Boom Fixing Bar 1 pcs Fixing the boom
Boom Holder Plastic Cover 1 sets Optional
Cabinet Fixing Bar 2 pcs Fixing the boom
Expansion Screws M16*150 4 sets Fixing the boom
Support Post 1 pcs Optional
Radio Emitter 1 pcs Optional
Keys 2 pcs For cabinet door
Remote Controller 2 pcs
Manual 1 pcs

Parking Barrier Gate Application

Suitable for indoor as well as outdoor parking area
Parking lots, goods yard, railway crossing, commercial premises, etc.

Parking Barrier Gate Functions & Features

1). DC permanent magnet synchronous motor(PMSM), servo control.
2). The motor has the same performance as the main motor of the CNC machine tool and the electric vehicle motor, it has high control precision, high torque density, good torque balance, low power conaumption, high efficiency and low noise.
3). More sensitive and reacting faster when reversing on obstacles.
4). With counting, delay auto-closing, and auto-aging test function.
5). 4-digit digital tube display, displays more information.
6). NO/NC wire control signal input are optional.
7). Integrated RS485 communication, infrared photocell and loop detector interface. RJ45 network, loop detector, and radar module can be added.

Parking Barrier Gate Technical Data

Model

WJDZ04SV1 (speed 3~5s adjustable)

Running Speed

3S

4S

5S

5S

5S

5S

Boom Type

Straight

Straight

Straight

90° Folding

2 Fence

3 Fence

Max Boom Length

4.5M

5M

6M

5M

4.5M

4M

Model

WJDZ04SV2 (speed 1.5~5s adjustable)

Running Speed

1.5s

2/3/4/5s

5s

5s

5s

Boom Type

Straight

Straight

90° Folding

2 Fence

3 Fence

Max Boom Length

3.5m

4.5m-6m

4m

4.5m

4m

Housing Dimension

362*325*1030mm

Input Voltage

AC220V±10%,AC110V±10%

Frequency

50/60HZ

Motor Voltage

DC310V

Enclosure Rating

IP54

Working Temperature

-35°C~+85°C

MTBF

5000000 times

Traffic Flow Application

3000 times/24hours

Max Motor Power

150W

Max Motor Speed

24r/min

Max Torque

240N.m
