1.What's High - power supply PCBA?
High - power supply PCBA refers to the printed circuit board assembly used in high - power supply systems. It is designed to handle and distribute high - power electrical signals, providing the necessary power for various electronic devices and systems.
2.Features of High - power supply PCBA:

• High - power handling capacity: It can handle large amounts of electrical power, usually several hundred watts or more.

• Good thermal performance: It has excellent heat dissipation capabilities to prevent overheating during high - power operation.

• High - reliability components: High - quality components are used to ensure stable operation and long - term reliability.
• Precise circuit design: The circuit design is optimized to minimize power loss and interference.
• Multiple output options: It can provide multiple output voltages and currents to meet the specific needs of different devices.
• Protection functions: It is equipped with various protection functions such as over - voltage protection, over - current protection, and short - circuit protection.

3.Common technical parameters of High power supply PCBAs:

4.Application Areas

• Industrial Automation

  • Power Inverters and Motor Drives: High current capacity and thermal stability ensure reliable operation in factory machinery and robotics.

  • Renewable Energy Systems: Solar inverters and wind turbine converters require efficient power conversion and heat management.

• Medical Equipment

  • MRI and CT Scanners: Coreless power solutions with 80dB EMI shielding meet the extreme magnetic field requirements of diagnostic devices.

  • High-Power Surgical Tools: Precision-controlled power delivery for laser or electrosurgical systems.

• Aerospace and Defense

  • Avionics and Radar Systems: MCPCBs and heavy copper layers ensure high reliability under thermal cycling and radiation exposure.

  • Satellite and UAV Power Systems: Compact, lightweight designs with strict adherence to AS9100D standards.

• Electric Vehicles (EVs)

  • Charging Stations: High-power modules (10kW+) with multi-interface designs support fast charging and grid integration.

  • Battery Management Systems (BMS): Thick copper traces and thermal vias enable safe, efficient energy distribution in EV powertrains.

• Telecommunications and Data Centers

  • 5G Base Stations: RF amplifiers and power supplies require low-loss materials (e.g., Rogers laminates) and EMI shielding for high-frequency performance.

  • Server Power Units: Multi-layer PCBs with dense power planes ensure stable, high-efficiency power distribution.

• Consumer Electronics

  • Gaming Consoles and High-End PCs: High-current VRMs (Voltage Regulator Modules) with thermal vias for CPU/GPU power delivery.

  • LED Lighting: MCPCBs enable high-brightness LED arrays in automotive headlights and industrial lighting.

Why Choose Ring PCB for high power supply PCBA?

Ring PCB’s Capabilities in High-Power Supply PCBA

By addressing the unique challenges of high-power supply PCBA manufacturing with innovation and dedication, Ring PCB has become a trusted partner for businesses worldwide. Partner with us today to power your next project.

1. Customized Solutions: Whether it's multi-layer designs, specific materials, or unique configurations, we tailor our services to meet your exact requirements.

2. Advanced Manufacturing Equipment: Our Shenzhen factory is equipped with state-of-the-art SMT lines, reflow ovens, and wave soldering machines for precise assembly.

3. High Layer Count: We manufacture up to 48-layer PCBs, enabling complex designs for power management systems.

4. One-Stop Service: From component procurement to final assembly, we provide comprehensive PCBA solutions.

17 Years of Excellence | Self-Owned Factory | End-to-End Technical Support
Core Advantage 1: Advanced Engineering for Precision PCB Manufacturing
• High-Density Stack-Up: 2-48 layer boards with blind/buried vias, 3/3mil trace/spacing, ±7% impedance control, ideal for 5G, industrial control, medical devices, and automotive electronics.
• Smart Manufacturing: Self-owned facility equipped with LDI laser exposure, vacuum lamination, and flying probe testers, adhering to IPC-6012 Class 3 standards.

Core Advantage 2: Integrated PCBA Services | One-Stop Turnkey Solutions
✓ Full Assembly Support: PCB fabrication + component sourcing + SMT assembly + functional testing.
✓ DFM/DFA Optimization: Expert engineering team reduces design risks and BOM costs.
✓ Rigorous Quality Control: X-ray inspection, AOI testing, and 100% functional validation for zero-defect delivery.

Core Advantage 3: Self-Owned Factory with Full Supply Chain Control
✓ Vertical Integration: Raw material procurement, production, and testing fully managed in-house.
✓ Triple Quality Assurance : AOI + impedance testing + thermal cycling, defect rate <0.2% (industry average: <1%).
✓ Global Certifications: ISO9001, IATF16949 and RoHS compliance.

Ring PCB not only offers professional PCB manufacturing, but also offer PCBA service, including component sourcing and SMT service with Samsung functional machine.

One of our core strengths lies in our 8-stage lead-free reflow soldering and lead-free wave soldering capabilities at our Shenzhen factory. These advanced soldering processes ensure high-quality assembly while adhering to global environmental standards, such as ISO9001, IATF16949 ,RoHS compliance.
