Specifications
Brand Name :
Tuorde
Model Number :
TRD12200
Certification :
CE/UN38.3
Place of Origin :
China
Model No. :
TRD12200
Capacity :
2560Wh
Enclosure Protection :
IP65
Dimensions :
522 x 238 x218 mm
Warranty :
5 year
Weight :
25Kg
Description

Tuorde Cleaning Equipment TRD12200 12V 200Ah Phosphate Lithium High Voltage EV Car

1. High integrated with less installation space.
2. Operating temperature,Charging:0℃~45℃,Discharging:-20℃~55℃
3. Without heavy metals and environment friendly.
4. Maintenance free, no memory effect.
5. Internal BMS with full protection,

Model No. TRD12200
Nominal Voltage 12.8 V
Nominal Capacity 200Ah
Energy 2560Wh
Communication No
Resistance ≤80 mΩ @ 50% SOC
Module Parallel or series(for option) Up to 4packs
Bluetooth function For option
Recommended Charge Current 40A
Maximum Charge Current 50A
Recommended Charge Voltage 14.6V
BMS Charge Cut-Off Voltage <14.6 V (3.65V/Cell)
Balancing Starting Voltage 3.4V/Cell
Maximum Continuous Discharge Current 100 A
Peak Discharge Current 300 A (1s)
Recommended Low Voltage Disconnect 10 V (2.5V/Cell)
BMS Discharge Cut-Off Voltage 8V (2.0V/Cell)
Short Circuit Protection ＜350 μs
Dimension (L x W x H) 522 x 238 x218 mm
20. 6x9.37 x 8.58”
Approx. Weight 55.1lbs(25Kg)
Terminal Type M8 terminal
Terminal Torque 80 ~ 100 in-lbs (9 ~ 11 N-m)
Case Material ABS+PC
Enclosure Protection IP65
Discharge Temperature -4 ~ 131 ºF (-20 ~ 55 ºC)
Charge Temperature -4 ~ 113 ºF (0 ~ 45 ºC)
Storage Temperature 23 ~ 95 ºF (-5 ~ 35 ºC)
BMS High Temperature Cut-Off 149 ºF (65 ºC)
Reconnect Temperature 131 ºF (55 ºC)
Certifications CE (battery)
UN38.3 (battery)
