Turning Tools Brazed Tip YG6 Tungsten Carbide Inserts
Turning Tools Brazed Tip YG6 Tungsten Carbide Inserts
Turning Tools Brazed Tip YG6 Tungsten Carbide Inserts
Turning Tools Brazed Tip YG6 Tungsten Carbide Inserts
Turning Tools Brazed Tip YG6 Tungsten Carbide Inserts
Turning Tools Brazed Tip YG6 Tungsten Carbide Inserts
Specifications
Brand Name :
HGalloytool
Model Number :
Type B
Certification :
ISO9001:2008
Place of Origin :
Hunan,Chian(Mainland)
MOQ :
5kg
Payment Terms :
T/T, Western Union
Supply Ability :
20 tons per month
Delivery Time :
20-30 days after order confirmed
Packaging Details :
plastic boxes inside and caton outside
Material :
Tungsten carbide
Color :
Grey
Specification :
C120/C125 etc
Grade :
YG6 YG8 K10 K20
Hardness :
HRA89-HRA92.9
Commodity Name :
Tungsten Carbide Welding Insert
Description

Type B2 Tungsten Carbide Brazed Tip/Welding Insert/YG6 Insert For Turning Tools


Product Description

Tungsten Carbide Welding Inserts have enough toughness shall be guaranteed by the maximum allowable size of the tips and by using a rather strong steel grade and heat treatment. Tungsten carbide inserts havea secure fixation which is guaranteed by the flutes of the tool holders and the quality in welding.

Application

ISO Code Grand Physical and mechanical properties Applications recommended
Density g/cm3 Hardness No Less Than HRA(HV) TRS No Less Than (Mpa)
K05 YG3 15 90.5 1300 Suitable for finishing of cast iron and nonferrous metal.

K10

 YG6X 14.8 91 1560 The finishing& semi-finishing of cast iron and nonferrous metals and also for the machining of manganese stell and hardening steel.
YG6A 14.7 91.5 1510

The finishing& semi-finishing of cast iron and nonferrous metals and also for the machining of manganese stell and hardening steel.

Suitable for the roughing of cast iron and light alloys and also for the milling of cast iron and low-alloy steel.
K15 YG6 14.9 89.5 1670
K20 YG8 14.6 89 1840 Suitable for the roughing of cast iron and light alloys and also for the milling of cast iron and low-alloy steel.
M10 YW1 13 91 1290 Suitable for finishing and semi-finishing of stainless steel and conventional alloy steel
YW3 12.9 92 1390

Suitable for finishing and semi-finishing of stainless steel and conventional alloy steel

The grade can be used for the semi-finishing of stainless steel and low-alloy steel and it is mainly used for the maching of railway wheel hubs.
YW4 12.3 92 1390
M20 YW2 12.9 90.5 1460
P10 YT05 12.6 92.5 1260 Suitable for the finihing and semi-finishing if steel and cast steel with a moderate feed rate and a rather high cutting speed.
YT15 11.3 91.0 1300
P20 YS14 11.4 91.5 1550 Suitable for the finishing and semi-finishing of steel and cast steel.YS25 is specially used for the milling of steel and cast steel.
YT14 11.4 90.5 1400
YS25 13.0 90.5 1780
P30 YT5 12.8 89.5 1560 Suitable for the heavy duty rough tuming of steel and cast steel with big feed rate at a medium and low speed under unfavorable working conditions.

Reference Drawing

Turning Tools Brazed Tip YG6 Tungsten Carbide Inserts

Product Photo

Turning Tools Brazed Tip YG6 Tungsten Carbide Inserts

Related Product

Company Information

Zhuzhou HGtool Tungsten Carbide Co., Ltd. was established on 2015 and located in Zhuzhou, Hunan province, specializing in the research and development, production, sales and technical services of new materials.

Customer Photo

Who We Serve:

The products are exported to more than ten countries and regions such as Europe, America and Southeast Asia.

Our Trade Show:

Quality Assurance

Packaging & Shipping

A. standard packaging

1).Plastic box with foam inside and carton outside.

2).The carton has foam inside and carton outside.

3).Inner box/inner packing material, outer plywood box (heavy duty product).

Customizable packaging: according to customer requirements for special packaging.

FAQ

Q1: Are you a factory or a trading company?

A: We are a factory. We have been focusing on Tungsten Carbide for over 20 years.

Q2:What is your principle for the samples?

A: We offer free samples if you are willing to pay the freight.

Q3:What is your delivery time?

A: Generally it is 5 to 7 days if your required goods are in stock, otherwise it takes 20 to 30 days when there is no stock.

Q4:Do you have any test reports or certificates?

A: Yes, we can offer certificate of ISO9000:2008, we also report our test results for your reference.

Q5: Do you provide after-sale service?

A: Yes. So if you find any problem after using our cutting tools, please do not hesitate to tell us, we’ll help you to solve it as soon as possible. Your any feedback to products is our way to improvement

Q6: What should I do before contacting?

A: You can provide specific dimensions or drawings, and tell us the quantity of each item, and your application of this item. Other special requirements is also available.

Q7:How to contact us?

A: Directly contact us from inquiry, or by whatsapp or wechat. Other ways you can also provide us.
