Type | Nail diameter(mm) | Nail size before molding(mm) | | Nail size after forming(mm) | Quantity of suturing staple | |
| | L | H | | | |
DF-PF-15R | 0.6 | 10.2 | 2.5 | 5.5*4 | 15 | |
DF-PF-15W | | 13 | 3.5 | 7.0*4 | 15 | |
DF-PF-25R | | 10.2 | 2.5 | 5.5*4 | 25 | |
DF-PF-25W | | 13 | 3.5 | 7.0*4 | 25 | |
DF-PF-35R | | 10.2 | 2.5 | 5.5*4 | 35 | |
DF-PF-35W | | 13 | 3.5 | 7.0*4 | 35 |
1) Ambient temperature (5-40) °C.
2) Relative temperature ≤ 80%.
3) Atmospheric pressure is 86.0Pa~106.0kPa.
Technical performance indicators:
1) nail molding size: W type: 6.8*4.5mm, Nail forming shape meets requirements.
2) The stapler should be made of stainless steel as specified in GB/T4234.
3) When the parts of the suturing device are used, the moving parts should be able to be smoothly pushed, and there must be no jamming or loosening;
4) After the suture is sutured, it can be smoothly taken out together with the nails;
