Specifications
Tread :
1820mm
Grade :
Medium Duty
Types of Suspension Systems :
Cross Arm Type
Shape :
Camionette
Axle Number :
3/4
Tire Number :
12/16
Self-dumping :
Not Self-dumping
ABS Anti-lock Braking System :
ABS Anti-lock Braking System
Material :
Steel
Condition :
New
Brake System :
Dual Air Brake System
Product :
Van Semi Trailer
Suspension :
Leaf Spring Suspension/Air Suspension
Transport Package :
Bulk or Container Transport or Customer Needs
Specification :
13750*2550*3650
Trademark :
Jin Rui
Origin :
Liangshan, Shandong Province, China
HS Code :
3708960665
Supply Ability :
3000set/Sets Per Month
Customization :
Available
After-sales Service :
1 Year
Warranty :
1 Year
Place of Origin :
China
Delivery Time :
Peak Season Lead Time: one month, Off Season Lead Time: one month
Payment Terms :
LC, T/T, D/P
Description
ABS Anti-lock Braking System 3/4 Axle Number Made Box/Van Logistics Transport Semi-Trailer
Cargo transport semi-trailer is a type of trailer designed to haul goods and materials over long distances using a tractor or truck as the power source. These trailers are commonly used in the shipping and transportation industry to transport a variety of products, including bulk commodities, manufactured goods, and equipment.ABS Anti-lock Braking System 3/4 Axle Number Made Box/Van Logistics Transport Semi-Trailer
Product Parameters

Manufacturer Liangshan Hongxiang Vehicle Co., Ltd.
Type Van Type semi trailer
Tare Weight Approx. 6.2 T
Dimension 12400*2500*3550mm
Loading Capacity 30-100 T
Axle 13T/16T, FUWA/BPW/SHENGRUN, etc
Rim 9.00*22.5/8.00-20/8.5-20
Suspension Mechanical suspension(Germany type or America type) or Air suspension
Leaf Spring 90(width)mm*13(thickness)mm*10 layer(especial for exporting market)
King pin Jost brand 2.0 or 3.5 inch
Spport leg Jost brand two speed
Main beam Height: 500mm, upper plate is 14mm, middle plate is 8mm, down plate is 16mm; Material is Q345B steel
Side beam 16mm channel steel (Material is Q235B steel)
Bottom Platform 3mm checquered steel plate
Side wall 600 mm height (can be customized)
Brake chamber Wabco re 6 relay valve; T30/30+T30 spring brake chamber; two units of 45L air tanks
ABS Optional
Twist locks Optional
Valve Wabco valve (especial for exporting market)
Light LED Light (especial for exporting market)
Voltage 24V
Receptacle 7 ways (7 wire harness)
Tool box One piece 1m *0.5m*0.5m ( size can be customized)
Painting Complete chassis sand blasting to clean rust, 1 cost of anticorrosive primer, 2 coats of final paint, color advised by customer
Shipping terms By bulk vessel, RORO, or 40HQ container
Any parts fitted could according to clients request, contact us to get more.
The size, color and logo can be customized. If you need more details, please contact me. We will supply the best service and price.
ABS Anti-lock Braking System 3/4 Axle Number Made Box/Van Logistics Transport Semi-Trailer
1. How To Buy From Us ? How to Pay? - quotation-offer-contract-1st payment-production-final payment-shipment-documentation; TT/LC/Western Union/Credit Card 2. If Our Vehicle/Trailer Can Couple With Your Tractor Head ? - 90% Of The Truck In The Market Can Coupling With Our Vehicle, As Howo, Shacman, Beiben, Volve... - If Other Brand Truck Head, Please Inform Our Sales Manager Before Order Placing 3. Whats The Time For Delivery & Arrival ? - If Standard Model We Have In Stock Can Ship It Out Within 10 Days After Payment. - If It Belongs To Customize Series, Ordinary Cases In 15 Days Can Be Finished For Shipment. - For Asian Countries, Ship Can Be Reached In 1-2 Weeks, If For African & Mid East & European Countries, 25 Workdays Will Be Achieved. 4. If We Can Provide Terms For Reducing Your Import Duties ? - Yes, Please Contact With Us, We Are Nationalized Manufacture With Tax Reduction
* Product Features

1. Convex and concave full beam: national patent product (national patent number: 200610062813.9), light weight, high strength.

2. Light weight: on the basis of light semi-trailer. Key components are further optimized to ensure the weight of the vehicle and achieve "lightweight" of the vehicle.

3, low bearing surface: optional small gooseneck tube and small 4 longitudinal beam structure, effectively reduce the height of the bearing surface, reduce the center of gravity, improve transportation safety.

* Advantage of our semi-trailer
Scientific design and quality assurance

The design process is based on the actual parameters of the tractor and trailer to ensure the best level of vehicle transport performance.
** Longitudinal beam overall camber structure characteristics, to ensure that the longitudinal beam lifetime downward without bending according to mechanical analysis, the use of a unique longitudinal beam overall camber structure to ensure the beam

Lifelong downward bending, effectively save fuel consumption under the same bearing load, to create the greatest economic value for users.
** High quality steel and OEM parts ensure product quality and condition.

The raw materials and parts of the semi-trailer are made of well-known brands at home and abroad, of which the key structural parts are specially supplied by the casting company, the largest supplier of special vehicle parts in China.
** Features suspension system eliminates tires

The unique new suspension ensures balanced load transfer between axles and eliminates any abnormal tire wear. The shaft snap ring is an integral casting, and the lower snap ring is a patented product to better ensure the stability and safety of the vehicle.
** Special steel and special railing structure has the characteristics of non-deformation and light weight.

All railings of the semi-trailer are made of high-strength square steel pipe welded, with light weight, high strength, high deformation resistance, and no deformation of the railings.
