Specifications
Model NO. :
ZZ4257N3247E1H
Power :
Diesel
Load Capacity :
31-40t
Emission Standard :
Euro 3
Drive Wheel :
6×4
Seats :
≤5
Horsepower :
＞450hp
Engine Capacity :
＞8L
Tire Certification :
ECE, GCC, ISO, DOT
Tire Design :
Tubeless
Condition :
New
Usage :
Towing Semi Trailer
Fuel Tank :
400L, 600L, 1000L
Driver Seat :
Air Suspension Seat
Color :
Customized
Cargo Box Material :
Carbon Steel
Steering System :
Hydraulic Steering with Power Assistance
Transport Package :
Nude Packing
Specification :
6.8x2.5x3.8m
Trademark :
Sinotruk
Origin :
China
HS Code :
8704109000
Supply Ability :
1000pieces/Year
After-sales Service :
6 Months
Warranty :
6 Months
Transmission Type :
Manual
Customization :
Available | Customized Request
Shipping Cost :
about shipping cost and estimated delivery time.
  :
Initial Payment Full Payment
Currency :
US$
Return&refunds :
You can apply for a refund up to 30 days after receipt of the products.
Certification :
SGS
Delivery Time :
7-15days
Description
Product Use

1. Definition of Tractor
A tractor is a versatile and powerful vehicle specifically designed to tow other vehicles or equipment on the road. It features one or more pairs of wheels and axles, making it indispensable for heavy transport. Common uses include towing semi-trailers, luxury yachts, and construction equipment, underscoring its critical role in heavy-duty logistics.
2. The Structure of the Tractor
A tractor is composed of several key components: the engine, transmission, tires, and frame. To enhance functionality and control, additional devices such as tow hooks, locking systems, and remote controls can be installed. These features collectively ensure high performance and operational efficiency.
3. Tractor Application Fields
1. Transportation: Tractors are essential in the long-distance freight industry. They tow semi-trailers and other large trucks, ensuring the safe and efficient delivery of goods to their destinations.
2. Construction Field: Tractors play a crucial role in construction, towing various heavy equipment such as excavators, bulldozers, and cranes to job sites, facilitating efficient project execution.

Basic Info.

Horsepower 350-550hp Engine Capacity >8L
Tire Design Radial Condition New
Usage Towing Semi Trailer Fuel Tank 400L, 600L, 1000L
Driver Seat Air Suspension Seat Transport Package Nude Packing
Trademark SINOTRUK HOWO Production Capacity 1000
Manual Transmission Type Gas Tractor in Nigeria Sinotruk Shandeka 6X4 Used Sitrak CNG
Manual Transmission Type Gas Tractor in Nigeria Sinotruk Shandeka 6X4 Used Sitrak CNG
Manual Transmission Type Gas Tractor in Nigeria Sinotruk Shandeka 6X4 Used Sitrak CNG

Manual Transmission Type Gas Tractor in Nigeria Sinotruk Shandeka 6X4 Used Sitrak CNGManual Transmission Type Gas Tractor in Nigeria Sinotruk Shandeka 6X4 Used Sitrak CNGManual Transmission Type Gas Tractor in Nigeria Sinotruk Shandeka 6X4 Used Sitrak CNG
Manual Transmission Type Gas Tractor in Nigeria Sinotruk Shandeka 6X4 Used Sitrak CNG
Manual Transmission Type Gas Tractor in Nigeria Sinotruk Shandeka 6X4 Used Sitrak CNG

Main Specifications:

Driver's Cab(One sleeper with A/C)
Model H7 Cab, with one sleeper beds, two seats, with A/C
Type Forward control cab, hydraulically tiltable by 60o
Construction Current standard all steel construction
Instrument panel Clearly visible,indicators of compressed air pressure,
coolant temperature, engine oil pressure and battery
charging
Seats 4-point support fully floating suspension + shock
absorbers driver adjustable & passenger fixed
Seat belts For driver & passenger
Glass Tempered safety glass
Sun visors Dual, adjustable
Mirrors Large, truck type convex
Wind screen wiper 3 arm wind screen wiper system with 3 speeds
Entertainment system FM/AM/SW, 4 band radio with cassette player, two speaker and antenna
Steering wheel Adjustable steering wheel
Horn Air horn
Panel LCD Panel with LED light

Engine
Engine brand SINOTRUK
Engine model WD615.47, 380hp
Emission Standard EURO II
Engine type Diesel 4-stroke direct injection engine,
6-cylinder in-line
with water cooling, turbo-charging &
Inter-cooling
Displacement 9.726 liters
Max. Output 371hp@2200rpm
Max. torque 1250Nm @1100-1600 rpm
Bore/Stroke 126/130mm
Compression ratio 17:1
Specific fuel consumption ≤193g/kW.h

Cooling System
Medium Water
Radiator heavy duty type
Cooling fan Visco static fan tropical type
Thermostat Opening at 70-80ºC
Warning device Audible & visual

Clutch
Type Φ430 Diaphragm type, Single dry frictional disc, Hydraulic boosting hydraulically operating with air assistance

Transmission
Type Heavy duty, manual fuller type
Model HW19710
No of speeds 10 forward + 2 reverse
Model Torque(Nm) Gear Ratios Oiling
(L)
1 2 3 4 5 6 7 8 9 10 R1 R2
HW19710 1900 14.28 10.62 7.87 5.88 4.38 3.27 2.43 1.80 1.34 1.00 13.91 3.18 12

Front Axle
Type HF7 tons steering with double T-cross section beam
Capacity 7000kg

Rear Axle
Type HC16(16 ton, punching-welding axle housing, double reduction driving axle, inter-wheel differential and differential lock)
Capacity 16T

Chassis
Frame Heavy duty, reinforced sub frame,
300mmx80mmx8mm
(inner: 280mmx70mmx7mm)
Front suspension semi-elliptic leaf springs with hydraulic telescopic double-action
shock absorbers and stabilizer, 1500mm
Rear suspension semi-elliptic springs ,and bogie springs, and stabilizer
, 1739mm

Air Intake System
Air cleaner type Heavy duty type
Pre filter Cyclone

Exhaust System
Capable of maintaining the sound level as low as possible.

Steering
Location Left hand
Model ZF 8098 (Made in Germany) hydraulic steering with power assistance
Variable ratios 22.2-26.2, 17.0-20.0
Max. pressure 170+10 bar
Max. output torque 7618 Nm
Weight 42 kg

Bumper
Installed heavy duty front and rear steel bumpers

Brake System
Service brake Dual circuit compressed air brake.
Parking brake Spring energy, compressed air operating on rear wheels
Assistant brake Engine exhaust valve brake

Wheels & Tires
Wheels Single front and dual rear
Tyres Double Coin brand,12.00R20
Quantity 13

Air Supply System
Warning device Audible & visual
Air line Heavy duty steel pipes

Electrical System
Operating Voltage 24V, Negative grounded; Starter 24V, 7.5KW
Battery type 2x12V, 165Ah/180Ah
Alternator 28V, 1500W
Cigar Lighter, horn, head lamps, fog lights, brake lights, indicators and reverse lamp

Dimensions
Wheel base 4600mm+1350
Overall length 6875mm
Overall width 2496mm
Overall height 3730mm

Our Factory
Manual Transmission Type Gas Tractor in Nigeria Sinotruk Shandeka 6X4 Used Sitrak CNG


Shipment

We typically ship our trucks by RO-RO vessel or bulk vessel. Alternatively, we can use specialized containers for transportation, ensuring the safe and efficient delivery of your purchase.
Manual Transmission Type Gas Tractor in Nigeria Sinotruk Shandeka 6X4 Used Sitrak CNG


Original Spare Parts
We provide original spare parts, supported by our comprehensive after-sales service system. Our After-market Division offers exceptional service, leveraging a streamlined supply chain to ensure rapid parts delivery.
Manual Transmission Type Gas Tractor in Nigeria Sinotruk Shandeka 6X4 Used Sitrak CNG

Our Product
Manual Transmission Type Gas Tractor in Nigeria Sinotruk Shandeka 6X4 Used Sitrak CNG
Thanks for Choosing Us
Q: How about the delivery time?
A: Most of our trucks and machinery are in stock and can be delivered within 7 days. For special orders, production typically takes around 30 days.

Q: How many units of trucks do you produce per year?
A: We produce nearly 30,000 units annually, with almost 5,000 units updated each month.

Q: How do you control the quality of your products?
A: Our factory features a standardized production workshop with well-trained workers. Each product undergoes a rigorous inspection process. We recondition trucks and machinery on a professional line to ensure top-notch quality.

Q: Do you accept custom orders? What is your minimum order quantity (MOQ)?
A: Yes, we accept custom orders. Our MOQ is 1 unit.
