SDLG Lingong G9300h 27tons Grader 4.8m 16-Foot Blade 242kw Powerful Motor Graders For Water Conservancy Construction Snow Discharge Bulldozing Slope Scraping
SDLG Lingong G9300h 27tons Grader 4.8m 16-Foot Blade 242kw Powerful Motor Graders For Water Conservancy Construction Snow Discharge Bulldozing Slope Scraping
SDLG Lingong G9300h 27tons Grader 4.8m 16-Foot Blade 242kw Powerful Motor Graders For Water Conservancy Construction Snow Discharge Bulldozing Slope Scraping
SDLG Lingong G9300h 27tons Grader 4.8m 16-Foot Blade 242kw Powerful Motor Graders For Water Conservancy Construction Snow Discharge Bulldozing Slope Scraping
Specifications
Brand Name :
SDLG
Model Number :
G9300h
Certification :
ISO9001
Place of Origin :
CHINA
MOQ :
1 Unit
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
500 Pieces/ Month
Delivery Time :
Full Payment 30-40 Work Days
Packaging Details :
by Sea/by Bulk/by Frame/by Container
Model :
G9300h
Fuel tank :
410L
Rated power :
242KW
Cutter size :
4876×680×25mm
Min. turning radius :
8.24m
Engine Model :
QSL8.9 - C325 - 33
Description

SDLG Lingong G9300h 27tons Grader 4.8m 16-Foot Blade 242kw Powerful Motor Graders For Water Conservancy Construction Snow Discharge Bulldozing Slope Scraping


Product Advantages

High-Productivity Power: The efficient 242 kW engine delivers strong, reliable performance to handle tough materials and maintain high work speeds, maximizing output on extensive job sites.

Exceptional Blade Capacity & Control: The standard 16-foot blade provides a significantly wider work path, enabling faster completion of large areas. Its advanced geometry and control systems ensure precise grading, sloping, and finishing.

Superior Stability & Traction: The heavy-weight design and optimized chassis provide outstanding stability and ground traction, allowing for powerful, controlled cuts and consistent performance on challenging terrain.

Operator-Focused Environment: The cab is designed for all-day comfort and efficiency, featuring excellent visibility, intuitive controls, and a focus on ergonomics to reduce fatigue and enhance productivity during long operations.

Built for Durability & Heavy Cycles: Constructed with premium, heavy-duty components, the G9300H is built to withstand rigorous use and provide reliable service with minimal downtime, offering excellent long-term value.

Overall Working Weight (kg) 27450
Rated Power (kW) 242
Max. Tractive Force (kN) 140
Overall Dimension(L×W×H)(mm) 10618*3428*3520
Max. Inclination Angle of Front Wheel (°) ±18
Max. Swing Angle of Front Axle (°) ±16
Max. Steering Angle of Front Wheel (°) ±50
Steering Angle of Articulated Frame (°) ±21
Cutter Size(LxHxT)(mm) 4876×680×25
Min. Turning Radius (m) 8.24
Cutting Depth of Blade (mm) 825
Max. Speed (km/h) 40
Engine Model QSL8.9 - C325 - 33
Emission Standard GB20891 - 2014 (stage 3 )
Fuel Tank Capacity (L) 410


Details Images

SDLG Lingong G9300h 27tons Grader 4.8m 16-Foot Blade 242kw Powerful Motor Graders For Water Conservancy Construction Snow Discharge Bulldozing Slope Scraping
SDLG Lingong G9300h 27tons Grader 4.8m 16-Foot Blade 242kw Powerful Motor Graders For Water Conservancy Construction Snow Discharge Bulldozing Slope Scraping
