Technology 4 Ton Mobile Straight Boom Lorry Crane With Max. Lifting Height of 6.8m
Technology 4 Ton Mobile Straight Boom Lorry Crane With Max. Lifting Height of 6.8m
Technology 4 Ton Mobile Straight Boom Lorry Crane With Max. Lifting Height of 6.8m
Technology 4 Ton Mobile Straight Boom Lorry Crane With Max. Lifting Height of 6.8m
Technology 4 Ton Mobile Straight Boom Lorry Crane With Max. Lifting Height of 6.8m
Technology 4 Ton Mobile Straight Boom Lorry Crane With Max. Lifting Height of 6.8m
Technology 4 Ton Mobile Straight Boom Lorry Crane With Max. Lifting Height of 6.8m
Technology 4 Ton Mobile Straight Boom Lorry Crane With Max. Lifting Height of 6.8m
Technology 4 Ton Mobile Straight Boom Lorry Crane With Max. Lifting Height of 6.8m
Technology 4 Ton Mobile Straight Boom Lorry Crane With Max. Lifting Height of 6.8m
Technology 4 Ton Mobile Straight Boom Lorry Crane With Max. Lifting Height of 6.8m
Technology 4 Ton Mobile Straight Boom Lorry Crane With Max. Lifting Height of 6.8m
Specifications
Feature :
TRUCK CRANE
Showroom Location :
Indonesia
Condition :
New
Application :
Construction
Rated Loading Capacity :
4 TON
Rated Lifting Moment :
6.8 T.M
Max. Lifting Height :
6.8 m
Span :
1989-3329 mm
Place of Origin :
Henan, China
Brand Name :
LIYUE
Warranty :
1 Year
Hydraulic Cylinder Brand :
MOOG
Hydraulic Pump Brand :
Changjiang
Hydraulic Valve Brand :
Liyuan
Engine Brand :
YUNNEI
UNIQUE SELLING POINT :
High operating efficiency
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Marketing Type :
Ordinary Product
Warranty of core components :
1 Year
Core Components :
Bearing, Pump
Weight (KG) :
1271 kg
Product name :
Truck Mounted Crane
Crane type :
Truck Crane Mobile Crane Hydraulic Crane
Hydraulic parts :
Famous Brand Hydraulic Parts
Capacity :
4 Ton Truck Crane
Boom type :
Hydraulic Straight Arm
Color :
Customer Requirements
Usage :
Construction Lifting
Rotation Angle :
360 Degree
Installation space :
850 mm
High quality :
Mobile Crane Lifting Capacity
Packaging Details :
Nude packing
Supply Ability :
3000 Unit/Units per Year
Price :
$8,100.00/units 1-2 units
Description

Dongfeng 4 Tons Truck Mounted Crane

Product Description
NOTE: The price is only for crane part.
Technology 4 Ton Mobile Straight Boom Lorry Crane With Max. Lifting Height of 6.8m

Project

Unit

Value

Crane Dimension

Crane Model

-

SQ 4T

Max. Lifting Capacity

kg

4000

Max. Lifting Height

m

11.5

Working Radius/ Span

m

2.1-7.93

Rotation Angle

º

360

Boom Raising Angle Scope

º

0-75

Boom Sections

Piece

3

Outrigger Quantity

Piece

2

Outrigger Span (Fully Extended)

mm

1989-3329

Crane Weight

kg

1271

Hydraulic Tank Capacity

L

30

Max. Flow Rate of Hydraulic Oil System

L/min

25

Hydraulic System Rated Pressure

Mpa

20

Installation Space

mm

850

Working Parameter

The Basic Boom Length

m

3.3-11.5

Max. Lifting Torque

T.m

6.8

Max. Slewing Speed

r/ min

2
Technology 4 Ton Mobile Straight Boom Lorry Crane With Max. Lifting Height of 6.8m
Technology 4 Ton Mobile Straight Boom Lorry Crane With Max. Lifting Height of 6.8m
Technology 4 Ton Mobile Straight Boom Lorry Crane With Max. Lifting Height of 6.8m
Product Description

Product Process

Famous Brand Hydraulic Parts for our Truck Crane

Technology 4 Ton Mobile Straight Boom Lorry Crane With Max. Lifting Height of 6.8m

Prodution Progress

Technology 4 Ton Mobile Straight Boom Lorry Crane With Max. Lifting Height of 6.8m

Packing & Shipping

Technology 4 Ton Mobile Straight Boom Lorry Crane With Max. Lifting Height of 6.8m

Client Visit

Technology 4 Ton Mobile Straight Boom Lorry Crane With Max. Lifting Height of 6.8m

Technology 4 Ton Mobile Straight Boom Lorry Crane With Max. Lifting Height of 6.8m

Certifications

Technology 4 Ton Mobile Straight Boom Lorry Crane With Max. Lifting Height of 6.8m

Optional Device

Technology 4 Ton Mobile Straight Boom Lorry Crane With Max. Lifting Height of 6.8m

Foreign Cases

Technology 4 Ton Mobile Straight Boom Lorry Crane With Max. Lifting Height of 6.8m

Related Products

Technology 4 Ton Mobile Straight Boom Lorry Crane With Max. Lifting Height of 6.8m

customer evaluation

Technology 4 Ton Mobile Straight Boom Lorry Crane With Max. Lifting Height of 6.8m
