02B 330 Double Convoluted Air Spring 2B Air Spring Drive Axle Air Bag
02B 330 Double Convoluted Air Spring 2B Air Spring Drive Axle Air Bag
02B 330 Double Convoluted Air Spring 2B Air Spring Drive Axle Air Bag
02B 330 Double Convoluted Air Spring 2B Air Spring Drive Axle Air Bag
02B 330 Double Convoluted Air Spring 2B Air Spring Drive Axle Air Bag
02B 330 Double Convoluted Air Spring 2B Air Spring Drive Axle Air Bag
02B 330 Double Convoluted Air Spring 2B Air Spring Drive Axle Air Bag
02B 330 Double Convoluted Air Spring 2B Air Spring Drive Axle Air Bag
02B 330 Double Convoluted Air Spring 2B Air Spring Drive Axle Air Bag
02B 330 Double Convoluted Air Spring 2B Air Spring Drive Axle Air Bag
Specifications
Brand Name :
YITAO
Model Number :
2B 5215/02B 260
Certification :
IATF16949
Place of Origin :
China
MOQ :
50 pieces
Price :
Negotiable in person
Payment Terms :
T/T
Supply Ability :
5000pieces/Month
Delivery Time :
1 ~ 30 days
Packaging Details :
Carton
OE Number :
02B 260
YITAO Number :
2B 5215
Shipping Time :
3-10 Days
Warranty :
12 Months
Type :
air spring, Suspension Spring
Main Material :
Rubber+Metal
Packing :
Neutral Packing Or Customized Packing
Description
02B 330 Double Convoluted Air Spring 2B Air Spring Drive Axle Air Bag
02B 330 Double Convoluted Air Spring
High-performance drive axle air bag designed for heavy-duty applications with reliable double convoluted construction.
Technical Specifications
Outer Diameterφ173mm
Weight5.008kg/2PCS
Net weight2.177kg
Package Dimensions25*25*25.5cm
Natural Height185mm
Maximum Height70mm
Minimum Height223mm
Extended Height230mm
Compressed Height75 mm
Top Plate Width132mm
Piston Width132mm
Product Documentation & Manufacturing Process
02B 330 Double Convoluted Air Spring 2B Air Spring Drive Axle Air Bag
02B 330 Double Convoluted Air Spring 2B Air Spring Drive Axle Air Bag
Factory Overview
02B 330 Double Convoluted Air Spring 2B Air Spring Drive Axle Air Bag
Quality Control Inspection
02B 330 Double Convoluted Air Spring 2B Air Spring Drive Axle Air Bag
Manufacturing Equipment
02B 330 Double Convoluted Air Spring 2B Air Spring Drive Axle Air Bag
R&D Center
02B 330 Double Convoluted Air Spring 2B Air Spring Drive Axle Air Bag
Assembly and Forming
02B 330 Double Convoluted Air Spring 2B Air Spring Drive Axle Air Bag
Vulcanization Shop
Images shown are for reference only. Actual product may vary slightly.
Delivery & Shipping Information
  • Delivery Time: Orders typically ship after payment receipt. Shipment completion within 1-30 business days based on order size
  • Packing Method: Standard brown carton packing; custom packaging available upon request
  • Shipping Marks: Standard weight and size display; custom shipping marks available
  • Transportation Methods: Sea, air, express delivery, railway, and combined transportation options
  • International Transport Notes: Strict standard packing to prevent damage. Contact us with any logistics questions
Frequently Asked Questions
  • Is the sample available?
    Yes, samples available via TNT, DHL, FEDEX or UPS (approx. 3-day delivery). Customers cover sample costs and airmail freight, refunded after order placement.
  • What is your warranty term?
    Full container load orders receive 1% free spare parts. 12-month warranty from shipment date. Customers responsible for replacement part costs during warranty period.
  • Can I use my own logo and design on products?
    Yes, OEM services welcomed.
  • I cannot find the items I want from your website, can you offer the products I need?
    Yes. We provide product sourcing services. Please provide detailed item requirements.
