4WD LHD/RHD Tri-Ring T3 Light Cargo Truck, 4WD Cargo Camions,4x4 Camoins
4WD LHD/RHD Tri-Ring T3 Light Cargo Truck, 4WD Cargo Camions,4x4 Camoins
Specifications
Brand Name :
Tri-Ring
Model Number :
T3
Certification :
CCC
Place of Origin :
Shiyan City,Hubei Province,China
MOQ :
2 Units
Price :
FOB$27600-$28500/Unit
Payment Terms :
T/T
Supply Ability :
100 Units/Month
Delivery Time :
40 working days
Packaging Details :
Nude,with wax coating(whole chassis with anti-rust treatment)
Color :
Optional
Cabin :
Optional
Engine power :
Optional
Wheelbase :
Optional
Tire type :
Optional
cargo box type :
Optional
A/C :
with
Power steering :
with
Clutch assistance :
with
Exhaust brake :
with
Description

4WD LHD/RHD Tri-Ring T3 Light Cargo Truck, 4WD Cargo Camions,4x4 Camoins

Vehicle Model T3
Manufacturer Hubei Tri-Ring Special Vehicle Co., Ltd
Place of Origin Shiyan City,Hubei Province,China
Drive type 4x4 Left Hand Drive
Approach/Departure angle 35/47(degree)
Wheelbase 3650mm
Cabin model T3-1995(with sleeper)
Engine model YC4E160-48(EGR+DOC+POC)
Engine displacement 4260ml
Max torque 600N.m/2600rpm
Emission level Euro4
Transmission 6DS60T-D(high speed)(FAST FULLER TECH)
Second-transmission(Transfer case)

HCF400(change 4x2 & 4x4 mode)

Max input torque 4000N.m

Max input speed 2800rpm

Ratio=1.0(high speed)

Ratio=2.22(low speed)

Pneumatic control gears shifting(0.4-0.6Mpa)
Front/Rear axle 4.2T/8T, 205 wheel reducer(ratio 6.578)
Front/Rear Wheel track 1860/1688mm
Front leaf spring 140(9/13)
Rear leaf spring 145(11+8/15+13)
Chassis frame 250(6.5+5), partly with 3 times thickness
Tire size 9.00R20-16

4WD LHD/RHD Tri-Ring T3 Light Cargo Truck, 4WD Cargo Camions,4x4 Camoins4WD LHD/RHD Tri-Ring T3 Light Cargo Truck, 4WD Cargo Camions,4x4 Camoins4WD LHD/RHD Tri-Ring T3 Light Cargo Truck, 4WD Cargo Camions,4x4 Camoins4WD LHD/RHD Tri-Ring T3 Light Cargo Truck, 4WD Cargo Camions,4x4 Camoins4WD LHD/RHD Tri-Ring T3 Light Cargo Truck, 4WD Cargo Camions,4x4 Camoins4WD LHD/RHD Tri-Ring T3 Light Cargo Truck, 4WD Cargo Camions,4x4 Camoins4WD LHD/RHD Tri-Ring T3 Light Cargo Truck, 4WD Cargo Camions,4x4 Camoins

4WD LHD/RHD Tri-Ring T3 Light Cargo Truck, 4WD Cargo Camions,4x4 Camoins

4WD LHD/RHD Tri-Ring T3 Light Cargo Truck, 4WD Cargo Camions,4x4 Camoins
