Specifications
Brand Name :
TR Solids Control
Model Number :
TRJBQ15
Certification :
API Q1,ISO9001
Place of Origin :
Xi'an,China
MOQ :
1
Price :
USD 275-45800 or Negotiable
Payment Terms :
L/C,T/T
Motor Power :
15kw
Impeller Speed :
60/72r/min
Impeller Diameter :
950mm
Impeller Quantity :
2
Weight :
480kg
Dimensions :
1330×890×747mm
Description

TRJBQ15 High-Performance Mud Agitator – Reliable Power for Efficient Drilling Fluid Mixing

Product Description

The TRJBQ15 Mud Agitator is an advanced mixing solution designed to ensure drilling fluids remain stable, homogenous, and effective throughout the drilling process. As an essential part of any solids control system, it prevents barite sag, solids accumulation, and mud property fluctuationsissues that can compromise drilling efficiency and borehole stability.

Built with a direct coupling transmission, the TRJBQ15 provides robust torque output while minimizing power loss, vibration, and maintenance costs. Its compact structure, explosion-proof safety features, and durable materials make it highly suitable for both land-based rigs and offshore platforms. Beyond oil and gas, this unit is also widely used in mining, construction, and tunneling projects where reliable slurry mixing is critical.

Features & Benefits

Direct Coupling Drive System Eliminates belt wear and slippage, ensuring smooth torque delivery and long-term reliability.

Powerful Agitation Capability 15 kW motor generates sufficient torque to mix heavy-weight drilling fluids up to 250 kg/m³.

High-Efficiency Gearbox Optional helical bevel gearbox provides up to 30% more energy efficiency than conventional worm gear drives.

Explosion-Proof Motor Fully certified for hazardous areas, in compliance with API, ISO, ATEX, and IECEx standards.

Heavy-Duty Construction Reinforced impeller blades, precision gearbox, and corrosion-resistant coatings extend service life even in harsh drilling environments.

Low Maintenance Fully sealed gearbox and wear-resistant components reduce downtime and repair frequency.

Technical Specifications

Model

TRJBQ15

Motor Power

15kw

Impeller Speed

60/72r/min

Impeller Diameter

950mm

Impeller Quantity

2

Weight

480kg

Dimensions

1330×890×747mm

Explosion-proof Standard

ExdIIBt4/IECEX/A-TEX

Remarks

Above weight and dimension exclude mud agitator shaft.

Technical Advantages

Efficient Power Transmission Direct coupling ensures full torque utilization with reduced energy loss.

Low-Noise Operation Precision gearbox delivers stable performance with minimal vibration.

Optimized Impeller Design Special blade geometry enhances fluid circulation, reducing dead zones and ensuring uniform mixing.

Flexible Installation Options Supports both horizontal and vertical mounting to suit different mud tank designs.

Enhanced Durability Resistant to abrasion, corrosion, and high-temperature mud conditions.

Customizable Configurations Available with different shaft lengths, impeller diameters, and power ratings to meet client-specific requirements.

Applications

Oil & Gas Drilling Prevents barite sag, improves cuttings suspension, and maintains fluid homogeneity.

Offshore Operations Safe, explosion-proof construction ensures reliable performance in marine environments.

Mining & Mineral Processing Effective for slurry mixing in ore separation, tailings treatment, and beneficiation.

Geothermal & Water Well Projects Maintains stable fluid properties in high-temperature wells.

Civil Engineering & Tunneling Ensures uniform bentonite/polymer slurry preparation for piling, tunneling, and trenchless works.

Advantages & Services

Trusted Expertise Backed by decades of design and manufacturing experience in solids control equipment.

Custom Solutions Tailor-made agitators designed to match client-specific drilling mud requirements.

Global Standards Compliance Built in accordance with API, ISO, ATEX, and IECEx for worldwide acceptance.

Reliable Delivery & Support Strong supply chain ensures fast shipment and spare parts availability.

Professional Service Technical team provides on-site installation support, commissioning, training, and long-term after-sales service.

Why Construction Professionals Choose TRJBQ15 Mud Agitator?

Keeps drilling fluids consistent and prevents solids settlement.

Compact yet powerful design, suitable for space-limited rigs.

Direct coupling drive ensures maximum energy efficiency and torque reliability.

Proven adaptability for both oil-based and water-based mud systems.

Designed for long service life, reduced maintenance, and cost savings.

About TR SolidsControl

TR SolidsControl is a professional manufacturer of drilling fluid equipment, supplying advanced solids control solutions for oil and gas, trenchless, and geothermal industries worldwide. Our commitment to innovation and quality ensures high-performance products and reliable service.
