Specifications
Place of Origin :
China
Brand Name :
Mittiway
Supply Ability :
100 Set/Sets per Month
Price :
$16,000.00/sets 1-4 sets
Model Number :
MTW-Z15P
Warranty :
1 Year
Type :
Other
Applicable Industries :
Food & Beverage Factory, Food Shop
Showroom Location :
None
Video outgoing-inspection :
Not Available
Warranty of core components :
1 Year
Core Components :
PLC, Motor
Condition :
New
Application :
Commodity, Chemical, Machinery & Hardware, APPAREL
Packaging Type :
Cartons, case
Automatic Grade :
Automatic
Driven Type :
Electric
Voltage :
220V/380V
Power :
2KW
Weight :
580 KG
Dimension(L*W*H) :
L1800*W1400*H1780mm
Key Selling Points :
high quality and effective after-sales service
Product name :
tray former
Keyword :
automatically box folding machine
Marketing Type :
Ordinary Product
Port :
Shenzhen
Description

Tray Former E Commerce Box Packing Erecting Machine

Product Description:

A corrugated tray former machine is a specialized piece of equipment used in the packaging industry to automatically fold and form trays or containers from corrugated cardboard or board materials. These trays are widely used for various applications, including food and beverage packaging, consumer goods packaging, and industrial packaging.

  1. Integration and Automation: Some corrugated tray former machines can be integrated into packaging lines or connected to other equipment, such as filling machines, sealing machines, or conveyors. This allows for seamless automation and improved workflow in the packaging process.

  2. User-Friendly Operation: Corrugated tray former machines are typically equipped with user-friendly control panels or interfaces, allowing operators to set parameters, adjust settings, and monitor the production process easily.

Features:

Commerce Box Tray Forming Machine Automatic Electric Driven TypeCommerce Box Tray Forming Machine Automatic Electric Driven TypeCommerce Box Tray Forming Machine Automatic Electric Driven TypeCommerce Box Tray Forming Machine Automatic Electric Driven Type

Model MTW-Z15P
Conveyor speed 720-900 Pcs/H
Carton size L250-350*W200-300*H60-90 mm
Power supply 220V,50Hz,2Kw
Air pressure 600NL/min,0.6-0.8Mpa
Discharge table height 730mm
Machine dimensions L1800*W1400*H1780mm
Machine weight 580kg

Company Profile:

Founded in 2015 and located in Dongguan, where be adjacent to Shenzhen port. Mittiway is an intelligent product packaging company integrating R&D, production and sales, which has a professional R&D department and sales department. Mittiway Smart has independently developed, produced and sold packaging machines such as bag inserter for carton, home appliance bagging machines, poly bag sealing machines, etc.; Box folding forming machines, and end of line packaging automation lines. At present, the products have been exported to Brazil, America, Germany, Argentina, South Korea and other 50 countries.

Commerce Box Tray Forming Machine Automatic Electric Driven TypeCommerce Box Tray Forming Machine Automatic Electric Driven TypeCommerce Box Tray Forming Machine Automatic Electric Driven TypeCommerce Box Tray Forming Machine Automatic Electric Driven Type

Support and Services:

Commerce Box Tray Forming Machine Automatic Electric Driven TypeCommerce Box Tray Forming Machine Automatic Electric Driven Type

FAQ:

Q1: Are you a factory ortrading company?

A1: We are factory with110vorkers in total.

Q2:What is your hot items?

A2: Our main products are tray erectors,tray former machine,bag inserter machine,bag folder

machine,bag sealer machine,carton erector,carton sealer

Q3:How about the Shipping Method?

A3: Our packing machines are mainly shipped by sea, or land transportation if it is next to

China ,and air shipments are all workable if the customer can afford the air freight. In one

words, we could do any shipments you wanted.

Q4:How about the delivery date?

A4: In General, the delivery date will be 35-65 working days for normal buy quantity. But if

bigger

order, please check with us further.

Q5:How about the label and the logo?

A5: Customize label and logo is workable.

Q6: How about the MOQ?

A6: 1set of machine.

Q7: What is the warranty?

A7:All our goods are 1 years warranty ,except the consuming parts.
