Custom Poly Automatic Bag Inserter Machine 220V / 380V Voltage
Custom Poly Automatic Bag Inserter Machine 220V / 380V Voltage
Custom Poly Automatic Bag Inserter Machine 220V / 380V Voltage
Custom Poly Automatic Bag Inserter Machine 220V / 380V Voltage
Custom Poly Automatic Bag Inserter Machine 220V / 380V Voltage
Custom Poly Automatic Bag Inserter Machine 220V / 380V Voltage
Custom Poly Automatic Bag Inserter Machine 220V / 380V Voltage
Custom Poly Automatic Bag Inserter Machine 220V / 380V Voltage
Custom Poly Automatic Bag Inserter Machine 220V / 380V Voltage
Custom Poly Automatic Bag Inserter Machine 220V / 380V Voltage
Custom Poly Automatic Bag Inserter Machine 220V / 380V Voltage
Custom Poly Automatic Bag Inserter Machine 220V / 380V Voltage
Specifications
Place of Origin :
China
Brand Name :
Mittiway
Packaging Details :
poly wood case
Price :
$16,000.00/sets 1-2 sets
Model Number :
MTW-T50
Showroom Location :
None
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Warranty of core components :
1 Year
Core Components :
PLC, Engine, Bearing, Gearbox, Motor
Condition :
New
Automatic Grade :
Automatic
Usage :
Other Forming Machine
Voltage :
220V/380V
Dimension(L*W*H) :
L2000*W1400*H1800mm
Warranty :
1 Year
Key Selling Points :
Long Service Life
Port :
Shenzhen
Description

MTW-T50 is an automatic bag making and inserting pack machine ,which adopts M-type PE film as the main consuming material. It can make bag and insert the bag automatically into the carton,which is mainly for the used boxes.The used boxes are soft and weak with its panels upright or hang down, we build the customized blowing type bag inserter specially for this kind of used cartons. The machine has small-footprint and simple structure, which is easily operated and easy maintenance. It is widely applied on oil, flour and food industry. The packing is high efficient and good-looking for products.

Specification
Model MTW-T50 Carbon steel
Machine dimension L2200W1800H2000mm
Packing size L:200~500mm W:200~400mm H:200~300mm
Width of the film 460~800mm (Sum the Length of the carton*2 +Width of the carton*2 +150mm)
Thickness of film 30/50/80/100 micron
Packing speed 4~7ctn/min
Net weight 1380kg
Power 5KW
Power supply 380V ,50/ 60Hz , 3Phase
Air pressure 8kg/cm³,0.6~0.8Mpa
Max current 10A

Company Profile
Custom Poly Automatic Bag Inserter Machine 220V / 380V Voltage
Custom Poly Automatic Bag Inserter Machine 220V / 380V Voltage
MITTIWAY PACKING MACHINE CO.,LTD is one of the professional leading packaging machine manufacturer in Guangdong province PRC. We specilized in the end of line packaging machine. Such as case erector ,case sealer, tray former,bag inserter, bag folder, bag sealer, automatic sealing &shrinking machine , and customized automatic case packer etc. We treat each engagement like it's our only one, and work hard to earn and keep your trust. We always think that our successes and our futures are tied together. Throughout the years, we have consistently delivered our clients with products and services with exceptional quality, value and measurable success.
Product Description
Custom Poly Automatic Bag Inserter Machine 220V / 380V Voltage
Custom Poly Automatic Bag Inserter Machine 220V / 380V Voltage
Custom Poly Automatic Bag Inserter Machine 220V / 380V Voltage
Custom Poly Automatic Bag Inserter Machine 220V / 380V Voltage
Custom Poly Automatic Bag Inserter Machine 220V / 380V Voltage
Custom Poly Automatic Bag Inserter Machine 220V / 380V Voltage
Our Exhibition
Cooperation brand
Custom Poly Automatic Bag Inserter Machine 220V / 380V Voltage
FAQ

Q1: Are you a factory ortrading company?

A1: We are factory with110vorkers in total.

Q2:What is your hot items?

A2: Our main products are tray erectors,tray former machine,bag inserter machine,bag folder

machine,bag sealer machine,carton erector,carton sealer

Q3:How about the Shipping Method?

A3: Our packing machines are mainly shipped by sea, or land transportation if it is next to

China ,and air shipments are all workable if the customer can afford the air freight. In one

words, we could do any shipments you wanted.

Q4:How about the delivery date?

A4: In General, the delivery date will be 35-65 working days for normal buy quantity. But if

bigger

order, please check with us further.

Q5:How about the label and the logo?

A5: Customize label and logo is workable.

Q6: How about the MOQ?

A6: 1set of machine.

Q7: What is the warranty?

A7:All our goods are 1 years warranty ,except the consuming parts.
