Industrial-grade 64CH VTX Transmitter (Pit/2W/4W) with IRC, 7-26V Input & Universal Mounting for Inspection Drones
Industrial-grade 64CH VTX Transmitter (Pit/2W/4W) with IRC, 7-26V Input & Universal Mounting for Inspection Drones
Industrial-grade 64CH VTX Transmitter (Pit/2W/4W) with IRC, 7-26V Input & Universal Mounting for Inspection Drones
Industrial-grade 64CH VTX Transmitter (Pit/2W/4W) with IRC, 7-26V Input & Universal Mounting for Inspection Drones
Industrial-grade 64CH VTX Transmitter (Pit/2W/4W) with IRC, 7-26V Input & Universal Mounting for Inspection Drones
Industrial-grade 64CH VTX Transmitter (Pit/2W/4W) with IRC, 7-26V Input & Universal Mounting for Inspection Drones
Industrial-grade 64CH VTX Transmitter (Pit/2W/4W) with IRC, 7-26V Input & Universal Mounting for Inspection Drones
Industrial-grade 64CH VTX Transmitter (Pit/2W/4W) with IRC, 7-26V Input & Universal Mounting for Inspection Drones
Industrial-grade 64CH VTX Transmitter (Pit/2W/4W) with IRC, 7-26V Input & Universal Mounting for Inspection Drones
Industrial-grade 64CH VTX Transmitter (Pit/2W/4W) with IRC, 7-26V Input & Universal Mounting for Inspection Drones
Specifications
Brand Name :
Kimghz technology
Model Number :
KH-ALV3304AC
Certification :
CE
Place of Origin :
Original/CHINA
MOQ :
10 Pieces
Price :
negotiation
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
10000pieces/month
Delivery Time :
3-8days
Packaging Details :
International Standard Packing
Model :
KH-ALV3304AC
RF Power :
4W
Protocol :
IRC- Tramp
Channels :
64CH
Frequency Range :
3.3GHz
Input Voltage :
7-26V
Weight :
40.4g
Dimensions :
50*36*16mm
Description
Industrial-grade 64CH VTX Transmitter (Pit/2W/4W) with IRC, 7-26V Input & Universal Mounting for Inspection Drones
Built for industrial and commercial drone applications such as aerial inspection, surveying, and surveillance, this rugged VTX module delivers rock-solid video transmission performance in harsh outdoor environments. It supports a flexible input voltage range of 7–26V (6S battery suggested for maximum reliability) and a constant 5V output, with 64 channels and three adjustable power modes (Pit, 2W, 4W) to adapt to short-range indoor scanning and long-range outdoor inspection tasks. Its optimized power consumption (1.34A at 12V, 0.64A at 25.2V) ensures prolonged operation, while integrated IRC functionality, heavy-duty SMA antenna connectors, JST-6Pin cable ports, and 30.5*30.5mm mounting holes enable seamless integration with industrial drone frames and accessories.
Technical Specifications
Brand Name Kimghz technology
Model Number KH-ALV3304AC
Origin China
Frequency 3.3GHz
Power Output Pit/2W/4W
Channels 64CH
Power Supply 7-26V
Protocol IRC
Frequency Range 3060MHz-3500MHz
Product Overview
This drone FPV VTX (Video Transmitter) is designed to enhance long-range FPV (First-Person View) flight experiences, integrating key features for reliable and flexible performance.
Industrial-grade 64CH VTX Transmitter (Pit/2W/4W) with IRC, 7-26V Input & Universal Mounting for Inspection DronesIndustrial-grade 64CH VTX Transmitter (Pit/2W/4W) with IRC, 7-26V Input & Universal Mounting for Inspection DronesIndustrial-grade 64CH VTX Transmitter (Pit/2W/4W) with IRC, 7-26V Input & Universal Mounting for Inspection DronesIndustrial-grade 64CH VTX Transmitter (Pit/2W/4W) with IRC, 7-26V Input & Universal Mounting for Inspection Drones
Performance Test Results
Industrial-grade 64CH VTX Transmitter (Pit/2W/4W) with IRC, 7-26V Input & Universal Mounting for Inspection Drones
Key Advantages
  • Mission-ready Durability: Robust connector design and stable power output ensure reliable operation in extreme temperature and weather conditions, ideal for industrial inspection tasks.
  • Wide Voltage Adaptability: The 7–26V input range eliminates the need for additional voltage regulators, simplifying the drone’s power system and reducing overall weight.
  • Multi-scenario Versatility: Three power modes and 64 channels make the module suitable for everything from low-power indoor mapping to mid-range outdoor infrastructure inspection.
