4.2GHz Digital Wireless Video Transmitter 4155-4530MHz 15 Channels For Wireless Transmission
4.2GHz Digital Wireless Video Transmitter 4155-4530MHz 15 Channels For Wireless Transmission
4.2GHz Digital Wireless Video Transmitter 4155-4530MHz 15 Channels For Wireless Transmission
4.2GHz Digital Wireless Video Transmitter 4155-4530MHz 15 Channels For Wireless Transmission
4.2GHz Digital Wireless Video Transmitter 4155-4530MHz 15 Channels For Wireless Transmission
4.2GHz Digital Wireless Video Transmitter 4155-4530MHz 15 Channels For Wireless Transmission
4.2GHz Digital Wireless Video Transmitter 4155-4530MHz 15 Channels For Wireless Transmission
4.2GHz Digital Wireless Video Transmitter 4155-4530MHz 15 Channels For Wireless Transmission
4.2GHz Digital Wireless Video Transmitter 4155-4530MHz 15 Channels For Wireless Transmission
4.2GHz Digital Wireless Video Transmitter 4155-4530MHz 15 Channels For Wireless Transmission
Specifications
Brand Name :
Kimghz technology
Model Number :
KH-42S10T
Certification :
CE
Place of Origin :
Original/CHINA
MOQ :
10 Pieces
Supply Ability :
10000pieces/month
Delivery Time :
3-8days
Packaging Details :
International Standard Packing
Price :
56$-399$
Model :
KH-42S10T
Input Voltage Requirement :
7-32V
Available Channels :
15CH
Temp Tolerance :
-10°C to +60°C
Power :
8-10W (200mW - 8-10W) (adjustable)
Freq Band :
4.2GHz
Weight :
60g (lightweight design)
Size :
80*45*22mm
Add-ons :
1080P/60fps (<100ms latency); HDMI/TTL; IP54; max 8km LOS (10W).
Description

4.2GHz Video Transmitter with 8–10W Peak RF Power


Product Overview


A compact, high-performance video transmission module designed for seamless outdoor and industrial applications.

It features a 4.2GHz frequency band (4155–4530MHz) with 15 selectable channels to minimize interference.

The transmitter offers adjustable RF power: 200mW, 400mW, 1W, 4W, and 8–10W peak output, supporting line-of-sight ranges up to 8km at 10W.

With a wide 7–32V power input, HDMI/TTL interfaces, 1080P/60fps video support, and <100ms latency, it is highly compatible for drones, surveillance, and remote monitoring systems.

It provides reliable operation in temperatures from -10°C to +60°C and features IP54 dust and water resistance for harsh environments.

Physical dimensions: 80×45×22mm, weight: 60g.

Technical Specifications


Item Details
Brand Name Kimghz technology
Model Number KH-42S10T
Origin China
Frequency 4.2GHz
Frequency Range 4155MHz–4530MHz
Channels 15CH
Power Output 8–10W (200mW, 400mW, 1W, 4W, 8–10W)
Power Supply 7–32V
Protocol IRC-Tramp
Dimensions 80×45×22mm
Weight 60g
Working Temperature -10°C to +60°C
Protection Level IP54
Video Interface HDMI / TTL
Video Resolution 1080P/60fps
Transmission Latency <100ms
Max Line-of-Sight Range Up to 8km (at 10W)

4.2GHz Digital Wireless Video Transmitter 4155-4530MHz 15 Channels For Wireless Transmission4.2GHz Digital Wireless Video Transmitter 4155-4530MHz 15 Channels For Wireless Transmission
Test Results

4.2GHz Digital Wireless Video Transmitter 4155-4530MHz 15 Channels For Wireless Transmission
Key Advantages

  • Power-Down Flexibility: Low-power modes (200mW-10W) extend device lifespan and reduce heat generation during short-range use.
  • Interference Resilience: 15 channels + wide frequency range enable quick adaptation to changing signal conditions, reducing downtime.
  • Rugged Compatibility: 7-32V power tolerance and stable 4.2GHz operation make it suitable for industrial, and outdoor adventure applications.
