High-Performance Roots Flowmeter with Exceptional Accuracy
High-Performance Roots Flowmeter with Exceptional Accuracy
High-Performance Roots Flowmeter with Exceptional Accuracy
High-Performance Roots Flowmeter with Exceptional Accuracy
Specifications
Brand Name :
YUNYI
Model Number :
GC series
Certification :
CE，ROHS
Place of Origin :
China
MOQ :
1pc
Price :
$1600-$2300/pcs
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
500PCS/week
Delivery Time :
7-10days
Packaging Details :
Carton box
Item :
Lpg Gas Flow Meter roots flowmeter
Line size :
DN25-DN200
Working Temperature :
-20 - 120 Deg.C
Signal Output :
4-20mA/Pulse/RS485
Power supply :
DC12-24V / 3.6V Lithium Battery
Working Pressure :
1.6 MPa/2.5MPa
Connection method :
Flange/Thread
Protection Class :
IP65/ IP68(optional)
Explosion Proof :
ExdII BT 6 / ExiaII CT4
Description

Description High-Performance Roots Flowmeter with Exceptional Accuracy

The Roots flowmeter, alternatively referred to as the gas girdle flowmeter, stands as a sophisticated and high - precision instrument primarily engineered for the accurate measurement of liquid flow within pipelines.

Whether monitoring continuous fluid movement or intermittent flow patterns, this device excels in delivering reliable and precise readings. It boasts exceptional accuracy, ensuring minimal measurement errors even in complex industrial scenarios. Built with robust materials and advanced technology, the flowmeter offers outstanding reliability and an extended service life.

Specification:

caliber DN25-DN250
nominal pressure 1.6MPa,2.5MPa

Accuracy

1.5,1.0
Installation method

Flange pipeline type
Power supply 24VDC,battery
Communcation RS485
Output pulse output,4-20mAcurrent

High-Performance Roots Flowmeter with Exceptional Accuracy

High-Performance Roots Flowmeter with Exceptional Accuracy

Features:

1.Precision: Advanced gear - interlocking ensures highly accurate flow measurement with minimal deviation.
2.Versatility: Handles low to high flow rates, adapting to diverse industrial needs.
3.Efficiency: Streamlined design reduces pressure loss, boosting system performance and saving energy.
4.Durability: High - grade, wear - resistant materials enable long - term use in tough conditions.
5.Ease of Use: User - friendly design allows for quick installation and intuitive operation.
6.Maintenance: Easy component access minimizes downtime and cuts maintenance costs.
