Specifications
Brand Name :
YUNYI
Model Number :
YFM4800E
Certification :
CE,ROHS,
Place of Origin :
China
MOQ :
10
Price :
USD$239/UNIT
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
5000 units per month
Delivery Time :
15-60 days
Packaging Details :
Standard export carton packing.
Measure accuracy :
±0.5%
Flow range :
0.3~15m/s
Working temperature :
-25°C~60°C
Flow output signal :
0~10mA/4~20mA /Pulse/MODBUS/HART
Supply voltage :
220VAC or 24VDC
Sensor connection :
Flanged, Threaded connection,Clamping connection type
Lining material :
PTFE, Soft rubber, Polyurethane rubber, F46 poly perfluoro ethyleneally
Protection class :
IP67
Description
Integrated electromagnetic flow meter is a combination of ZFG electromagnetic flow meter sensor and ZFH series signal converter. The signal converter has IP67 protection requirements.
ZFG integrated electromagnetic flow meter is mainly used to measure the volume flow of various acids, salt solutions, pulp, mud and other conductive liquids, or liquid-solid two-phase media. It is widely used in chemical industry, mining and metallurgy, water supply and drainage, sewage treatment, food, paper, sugar, port dredging and other departments.
This flow meter can be matched with display, recording instrument, totalizator or regulator to detect, accumulate, adjust and control the flow... (text cut off at the end)
Fearture
  • The sensor adopts an integral welded structure with good sealing performance
  • Simple and reliable structure, no moving parts inside, almost no pressure loss
  • The recording accuracy is not affected by changes in physical parameters such as pressure, temperature, density, viscosity, etc. of the measured medium
  • With conductivity measurement function, it can judge whether the sensor is empty or not
  • Using 16-bit embedded microprocessor, fast operation speed and high precision
  • With bidirectional flow measurement function, it can display forward and reverse flow, percentage, flow rate
  • There are three totalizator inside, showing the forward, reverse accumulation and difference accumulation respectively
  • With RS485 or RS232C digital communication signal output
  • With digital processing, strong anti-interference ability, reliable measurement and high precision
  • The ultra-low EMI switching power supply is suitable for a large range of power supply voltage changes and has good EMC resistance
  • Including Chinese and English menu operation, easy to use, easy to operate, easy to learn and understand
  • Self-diagnostic information and troubleshooting
  • Explosion-proof type (flameproof type) available
