Customizable 58-62 HRC Transmission Gear Shaft in Long-Term Continuous Operation Equipment
Customizable 58-62 HRC Transmission Gear Shaft in Long-Term Continuous Operation Equipment
Specifications
Brand Name :
YIZGEAR
Place of Origin :
CHINA
MOQ :
200 Sets
Payment Terms :
L/C, T/T
Supply Ability :
500 Sets/Month
Delivery Time :
30 Days
Packaging Details :
Plywood Crate
Quality Grade :
ISO 6-7 Grade
Hardness :
58-62 HRC
Surface Finish :
Smooth
Length :
Customized
Precision :
High Precision
Teeth Number :
Custom
Description

1) Descriptions of Transmission Gear Shaft

The performance of transmission components that require regular lubrication relies on lubricants to reduce friction and wear.

2) Features of Transmission Gear Shaft

  • High lubrication requirements: grease or oil bath lubrication required.
  • Critical sealing: protection against contaminants (e.g. labyrinth seals).
  • Long maintenance intervals: quality design reduces downtime.

3) Working Principle of Transmission Gear Shaft

The lubricant forms an oil film on the mating surfaces of the gears, reducing contact stresses and heat build-up.

4) Application of Transmission Gear Shaft

Long-term continuous operation equipment such as wind turbine gearboxes and ship propulsion systems.

Technical Specifications
Parameter Specification
Custom Made Available
Gear Profile Type Gleason
Manufacturing Process Gear Grinding
Teeth Grinding Included
Module (M) Custom
Number of Teeth (Z) Custom
Pressure Angle (α) Custom
Lead Angle Custom
Accuracy Grade ISO 6 Grade
Heat Treatment Carburizing
Surface Hardness 58-62HRC
Steel Code Grades Comparison
CHINA/GB ISO ГΟСТ ASTM JIS DIN
45 C45E4 45 1045 S45C CK45
40Cr 41Cr4 40X 5140 SCr440 41Cr4
20CrMo 18CrMo4 20ХМ 4118 SCM22 25CrMo4
42CrMo 42CrMo4 38XM 4140 SCM440 42CrMo4
20CrMnTi 18XГT SMK22
20Cr2Ni4 20X2H4A
20CrNiMo 20CrNiMo2 20XHM 8720 SNCM220 21NiCrMo2
40CrNiMoA 40XH2MA/40XHMA 4340 SNCM439 40NiCrMo6/36NiCrMo4
20CrNi2Mo 20NiCrMo7 20XH2MA 4320 SNCM420
Production Equipment

Customizable 58-62 HRC Transmission Gear Shaft in Long-Term Continuous Operation Equipment

Manufacturing Process

Customizable 58-62 HRC Transmission Gear Shaft in Long-Term Continuous Operation Equipment
