Semi-Automatic Motor Coil Winding Machine With 5.5kw Rotating Power And Large 1500mm Winding Diameter
Semi-Automatic Motor Coil Winding Machine With 5.5kw Rotating Power And Large 1500mm Winding Diameter
Specifications
Brand Name :
STT
Model Number :
MW1500
Place of Origin :
China
MOQ :
1 set
Price :
negotiable
Payment Terms :
T/T,L/C
Supply Ability :
100 sets per year
Delivery Time :
25 days
Packaging Details :
seaworthy packing
Product name :
motor coil winding machine
Usage :
winding motor coil
Winding Diameter :
1500mm
Color :
as requested
Rotating Power :
5.5kw
Rotating Speed :
0 ~ 80rpm
Machine Height :
1800mm
Warranty :
12 months
Description

Máquina de enrolar bobinas de motor Semi Automatic Motor Coil Winding Machine


Introduction of motor coil winding machine MW1500

Motor coil winding machine MW1500 is a professional wire coiling machine for winding motor coils and other similar products. The motor coil winding machine is provided with a counter for counting the number of turns when winding. The winding speed of the motor coil winding machine can be adjusted through a potentiometer on the board. The motor coil winding machine can stop and start running through its foot pedal. The motor coil winding machine is equipped with adjustable movable blocks. The winding former can be fixed on the two movable blocks. The distance between the two blocks can be adjusted with rotating screw rod of the mold and the adjustment range is 200 ~1500mm.


Main components of motor coil winding machine MW1500

1.Main frame

2.Electric control cabinet

3.Foot pedal

Main parameters of motor coil winding machine MW1500

Typical standard specifications of motor coil winding machine MW1500 are shown below and the motor coil winding machine can also be manufactured as requested.

Center Height:

900mm

Adjustable Range:

200 ~ 1500mm

Winding Speed:

0 ～ 80rpm

Counting Range:

0 ～ 9999.9

Motor Power:

5.5KW

Maximum Capacity:

300KG

Total Weight:

500KG

Dimension(L*W*H):

1200X670X1700mm

Semi-Automatic Motor Coil Winding Machine With 5.5kw Rotating Power And Large 1500mm Winding Diameter

Fig 1: Motor coil winding machine MW1500's full view


Semi-Automatic Motor Coil Winding Machine With 5.5kw Rotating Power And Large 1500mm Winding Diameter

Fig 2: Motor coil winding machine MW1500's control board

Semi-Automatic Motor Coil Winding Machine With 5.5kw Rotating Power And Large 1500mm Winding Diameter

Semi-Automatic Motor Coil Winding Machine With 5.5kw Rotating Power And Large 1500mm Winding DiameterSemi-Automatic Motor Coil Winding Machine With 5.5kw Rotating Power And Large 1500mm Winding DiameterSemi-Automatic Motor Coil Winding Machine With 5.5kw Rotating Power And Large 1500mm Winding Diameter
