Heavy Duty Copper Foil Winding Machine with Two Foil Decoilers Two Insulation Decoilers and 12 Months Warranty
Heavy Duty Copper Foil Winding Machine with Two Foil Decoilers Two Insulation Decoilers and 12 Months Warranty
Specifications
Brand Name :
STT
Model Number :
BRJ1200-2
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
USD35000-45000
Payment Terms :
T/T,L/C
Delivery Time :
45 days
Packaging Details :
seaworth packing
Product name :
transformer foil winding machine
Function :
winding foil coil
Cu foil thickness :
0.2 ~ 2.0mm
Al foil thickness :
0.3 ~ 3.0mm
Welding mode :
TIG
Welding machine :
1 set
Rotating power :
22kw
Warranty period :
12 months
Description

Heavy Duty Winder Machine Transformer Copper Foil Winding Machine


Description of copper foil winding machine BRJ1200-2

Copper foil winding machine BRJ1200-2 is a professional winding machine, which is mainly used to winding cast resin transformer coils and other similar products. With two foil decoilers and two insulation decoilers, the foil winding machine can handle one or two layers of foil and one or two layers of insulation paper. The foil winding machine is provided with photoelectric sensing for correcting the foil’s position when the foil is wound. With PLC and HMI, the foil winding machine is with high automation and easy operation.


Main components of copper foil winding machine BRJ1200-2

· Main frame

· Winding unit

· Foil decoiler

· Insulation decoiler

· End-fill strip feeder

· Cleaning system

· Cutting system

· Edge alignment system

· Automatic welding unit

· Electronic control system

Technical parameters of copper foil winding machine BRJ1200-2

Typical standard specifications of copper foil winding machine BRJ1200-2 are shown below and the copper foil winding machine can also be manufactured as requested.

Foil width:

200 - 1,200mm

Max Wounded Coil OD:

Ø800mm

Al Foil Thickness:

0.3 - 3.0 mm

Cu Foil Thickness:

0.2 - 2.0 mm

Conductor Material OD.:

Ø1,000mm

Conductor Material ID.:

Ø500mm

Foil Decoiler Expanding Range:

Ø480 - 520mm

Winding Power:

22KW

Welding Mode:

TIG

Cutting Mode:

Electric rolling shear

Insulation Decoiler:

2 pcs

End-fill Strip Feeder:

8 pcs

Edge Alignment System:

Photoelectric sensing

Counting Turns Range:

0 - 9999.9

Heavy Duty Copper Foil Winding Machine with Two Foil Decoilers Two Insulation Decoilers and 12 Months Warranty
Fig 1: Copper foil winding machine BRJ1200-2's side view

Heavy Duty Copper Foil Winding Machine with Two Foil Decoilers Two Insulation Decoilers and 12 Months Warranty
Fig 2: Copper foil winding machine BRJ1200-2's back view
