Semi Automatic Wire Winding Equipment Transformer Coil Winding Machine
Semi Automatic Wire Winding Equipment Transformer Coil Winding Machine
Specifications
Brand Name :
STT
Model Number :
GDY-5T
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
negotiable
Payment Terms :
T/T,L/C
Supply Ability :
100 sets per year
Delivery Time :
20 days
Packaging Details :
seaworthy packing
Product name :
Transformer Coil Winding Machine
Display :
Digital mode
Material :
Steel
Winding Motor :
11KW
Operation Mode :
Semi Automatic
Rotating Speed :
0 ~ 40rpm
Machine Color :
optional
Warranty :
12 months
Description

Semi Automatic Wire Winding Equipment Transformer Coil Winding Machine



Description of transformer coil winding machine GDY-5T

Transformer coil winding machine GDY-5T is a professional transformer coil winding equipment. This kind of transformer coil winding machine can be used to wind copper wire or aluminium coil to make wire coils. The transformer coil winding machine is provided with a digital counter, which makes the transformer coil winding machine be able to count the turns when winding. Moreover, the number of turns can be preset, after completing winding the preset number of turns, the machine will stop automatically. The transformer coil winding machine’s rotating speed can be adjusted through a potentiometer on the control board. Starting or stopping the transformer coil winding machine can be done through the foot pedal. The transformer coil winding machine features slow starting, smooth running, high torque, and so on.


Main components of transformer coil winding machine GDY-5T

o Main frame

o Square shaft

o Split tailstock

o Foot pedal

o Counter

o Control board


Main parameters of transformer coil winding machine GDY-5T

Typical standard specifications of transformer coil winding machine GDY-5T are shown below and the transformer coil winding machine can also be manufactured as requested.

Center Height:

1000 mm

Winding Speed:

0 ~ 40rpm

Counting Range:

0 ~ 9999.9

Max. Loading:

5000kg

Winding Power:

11kw

Machine Weight:

700kg

Power Supply:

3-phase 380V 50Hz


Semi Automatic Wire Winding Equipment Transformer Coil Winding Machine

Fig 1: Transformer coil winding machine GDY-3T's full view
