High-Precision Silicon Steel Slitter with ±0.1mm Cutting Accuracy 120 m/min Feeding Speed and 5000 kg Coil Weight Capacity
High-Precision Silicon Steel Slitter with ±0.1mm Cutting Accuracy 120 m/min Feeding Speed and 5000 kg Coil Weight Capacity
Specifications
Supply Ability :
100 sets per year
Product name :
slitting line
Model Number :
ZJX1250
Machine color :
as requested
Price :
negotiable
Material core outer Diameter :
Ø1200mm, maximum
Material core inner Diameter :
Ø500mm
MOQ :
1 set
Delivery Time :
90 days
Sheet width :
500 ~ 1250mm
Payment Terms :
T/T
Function :
slit silicon steel sheet
Sheet thickness :
0.23 ~ 0.5mm
Cutting accuracy :
±0.1mm
Certification :
CE
Place of Origin :
China
Material :
silicon steel sheet
Packaging Details :
seaworthy packing
Brand Name :
STT
Warranty :
12 months
Description

High-Precision Silicon Steel Sheet Slitter | CRGO Coil Slitting Machine for Transformer Cores (ZJX1250)

Product Overview

The High-Precision Silicon Steel Slitter ZJX1250 is a robust, automated solution engineered specifically for processing electrical steel (CRGO/CRNGO) coils. It accurately transforms wide silicon steel sheets into narrow strips of precise widths, required for manufacturing transformer legs, yokes, and other electrical core laminations. This advanced core slitting machine integrates cutting-edge control logic powered by a PLC system and an intuitive HMI touch screen. This allows operators to easily set slitting parameters, monitor production speeds, and ensure flawless, consistent output with minimal downtime.


Performance & Design Advantages

  • Optimized for Electrical Steel: Engineered to handle the unique properties of CRGO silicon steel, minimizing material stress during processing.

  • High-Precision Cutting: Achieves a superior width tolerance of ±0.10mm and extremely low burr levels (≤0.02mm), crucial for reducing transformer core loss.

  • User-Friendly Automation: The advanced PLC and touch-screen interface make parameter setting, speed adjustment, and system diagnostics straightforward and efficient.

  • Heavy-Duty Capacity: Robustly designed to process massive coils weighing up to 5,000 kg and with a feeding speed of up to 120 m/min.

  • Comprehensive Warranty: Backed by a full one-year warranty and responsive technical support.

Technical Specifications

Engineering Parameter ZJX1250 Standard Configuration
Compatible Material Type High-Grade Silicon Steel (CRGO/CRNGO)
Material Thickness Range 0.23 mm – 0.5 mm
Input Coil Width (Slitting Width) 40 mm – 1200 mm
Maximum Coil Weight 5,000 kg
Max Feeding Speed 120 m/min
Slitting Width Tolerance ±0.10 mm
Maximum Slitting Burr ≤0.02 mm
Standard Cutter Quantity 6 Sets
Coil Inner Diameter (ID) 495 mm – 510 mm
Coil Outer Diameter (OD) 1200 mm
Decoiler Expanding Range 470 mm – 520 mm
Total Drive Power 55 kW
Control System Architecture Industrial PLC + HMI Touch Screen
Auxiliary Systems Hydraulic Station, Pneumatic System

Complete Production Line Components

The core slitting machine ZJX1250 is a complete, integrated system designed for continuous, high-volume industrial operation:

  1. Material Handling Trolley: Ensures safe loading and unloading of heavy coils.

  2. Heavy-Duty Decoiler: Provides smooth, controlled uncoiling of the master roll.

  3. Advanced Material Receiver & Movable Guide: Guarantees proper strip tracking before cutting.

  4. High-Precision Slitting Head: Features specialized cutters for thin, hard electrical steel.

  5. Synchronized Tensioner & Winder: Maintains constant tension for tight, uniform wound strips.

  6. Central Control Console: Houses the PLC, HMI, and electrical control systems.


Fig 1: Core slitting machine ZJX1250's front view


Fig 2: Core slitting machine ZJX1250's winder
