Transformer Aluminium And Copper Wire Coil Winding Machine Electrical Automatic
Transformer Aluminium And Copper Wire Coil Winding Machine Electrical Automatic
Specifications
Brand Name :
STT
Model Number :
ZPX1400
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
negotiable
Payment Terms :
T/T, L/C
Supply Ability :
100 sets per year
Delivery Time :
35 days
Packaging Details :
seaworthy packing
Product name :
automatic coil winding machine
Usage :
winding transformer coil
Wire type :
round or flat
Wire material :
copper / aluminium wire
Round wire size :
0.3- 5.0mm
Flat wire size :
5x12mm
Winding power :
7.5kw
Winding speed :
60rpm
Description

Transformer Copper And Aluminium Wire Coil Electrical Winder Automatic Coil Winding Machine

Description of automatic coil winding machine ZPX1400

Automatic transformer coil winding machine ZPX1400 is a kind of special winding machine to wind wire coil for making oil type transformer. This kind of automatic coil winding machine is can be used to wind round or flat wire and the maximum winding width is 1400mm. Control system of the automatic coil winding machine is based on PLC, which guarantees high automation of the automatic coil winding machine. The automatic coil winding machine can be used to wind different specifications of coils with different parameters input through the touch screen. It is very easy to operate the automatic coil winding machine.

Main Features of automatic coil winding machine ZPX1400

  • slow starting,
  • smooth running
  • full function
  • high automation
  • High torque
  • High precision

Technical Parameters of automatic coil winding machine ZPX1400

Typical standard specifications of automatic coil winding machine ZPX1400 are shown below, however the automatic coil winding machine can also be manufactured as requested.

Center Height: 900mm
Winding Shaft Size: 50x50x1700mm
Insulation Paper Dereeler Quantity: 1 pc
Winding Power: 7.5Kw
Winding Speed: 0～60 Rpm
Speed Regulation: stepless speed regulation
Maximum Rectangular Wire Size: 5x14mm
Round Wire Diameter: 0.3 ～ 5.0mm
Maximum Winding Width: 1400mm
Maximum Coil Weight: 1000kg
Counting Mode: 5-digit counting
Maximum Turns Preset: 9999.9
Counting Range: 0 ～ 9999.9

Transformer Aluminium And Copper Wire Coil Winding Machine Electrical Automatic

Fig 1: Automatic coil winding machine ZPX1400's front view

Transformer Aluminium And Copper Wire Coil Winding Machine Electrical Automatic

Fig 2: Automatic coil winding machine's inaulation paper dereeler

Transformer Aluminium And Copper Wire Coil Winding Machine Electrical AutomaticTransformer Aluminium And Copper Wire Coil Winding Machine Electrical AutomaticTransformer Aluminium And Copper Wire Coil Winding Machine Electrical AutomaticTransformer Aluminium And Copper Wire Coil Winding Machine Electrical AutomaticTransformer Aluminium And Copper Wire Coil Winding Machine Electrical AutomaticTransformer Aluminium And Copper Wire Coil Winding Machine Electrical AutomaticTransformer Aluminium And Copper Wire Coil Winding Machine Electrical AutomaticTransformer Aluminium And Copper Wire Coil Winding Machine Electrical Automatic
