The GIS Partial Discharge and AC Withstand Voltage Test System is a professional high-voltage testing solution designed for insulation withstand testing and partial discharge measurement of Gas Insulated Switchgear (GIS), Gas Insulated Line (GIL) and related high-voltage equipment.

The system combines high-voltage AC testing, partial discharge measurement, high-precision voltage measurement, digital data acquisition and intelligent control into an integrated testing platform.

It is suitable for GIS manufacturers, power utilities, substations, EPC contractors, commissioning companies, high-voltage laboratories and electrical equipment testing centers.

Current GIS testing solutions commonly combine AC withstand testing with PD measurement and are used for both factory testing and on-site commissioning.

• GIS AC withstand voltage test
• GIS partial discharge test
• GIL AC withstand test
• GIS insulation performance verification
• Power-frequency withstand test
• Variable-frequency AC withstand test
• Partial discharge measurement
• PD inception voltage measurement
• PD extinction voltage measurement
• PD pattern analysis
• High-voltage measurement
• Test data recording
• Automatic test control
• Test report generation

• GIS
• GIL
• HGIS
• GIS busbar
• GIS circuit breaker
• GIS disconnector
• GIS grounding switch
• GIS instrument transformer
• GIS insulator
• GIS bushing
• Spacer insulator
• Other HV switchgear components

GIS Factory Testing

Used for routine testing and type testing during GIS manufacturing.

Substation Commissioning

Used to verify GIS insulation performance after transportation and installation.

Post-Maintenance Testing

Used after major GIS maintenance, modification or component replacement.

High Voltage Laboratory

Suitable for research, development and certification testing.

Problem 1: GIS passes withstand voltage but still has internal defects.

AC withstand testing and PD measurement provide different information. PD testing can help identify localized insulation defects that may not be revealed by a simple withstand test.

Problem 2: External noise interferes with PD measurement.

For sensitive GIS PD testing, the test system should be designed with low background PD and appropriate shielding, grounding and measurement technology.

Problem 3: Large GIS has high capacitive load.

The test system should be selected according to GIS capacitance, required test voltage, frequency range and test duration.
