250ton China Supply Foundry Plant Use Steel Motorized Handling Transport Transfer Cart
250ton China Supply Foundry Plant Use Steel Motorized Handling Transport Transfer Cart
250ton China Supply Foundry Plant Use Steel Motorized Handling Transport Transfer Cart
250ton China Supply Foundry Plant Use Steel Motorized Handling Transport Transfer Cart
250ton China Supply Foundry Plant Use Steel Motorized Handling Transport Transfer Cart
250ton China Supply Foundry Plant Use Steel Motorized Handling Transport Transfer Cart
250ton China Supply Foundry Plant Use Steel Motorized Handling Transport Transfer Cart
250ton China Supply Foundry Plant Use Steel Motorized Handling Transport Transfer Cart
250ton China Supply Foundry Plant Use Steel Motorized Handling Transport Transfer Cart
250ton China Supply Foundry Plant Use Steel Motorized Handling Transport Transfer Cart
250ton China Supply Foundry Plant Use Steel Motorized Handling Transport Transfer Cart
250ton China Supply Foundry Plant Use Steel Motorized Handling Transport Transfer Cart
Specifications
MOQ :
1 Piece
Price :
US$3000-3500
Place of Origin :
Xinxiang
Brand Name :
BETTER
Packaging Details :
Single Package: Dimensions 300×200×100 cm; Gross Weight 1000 kg; Quantity per Package 1 unit.
Delivery Time :
15-30 days
Payment Terms :
L/C,T/T
Supply Ability :
50 Sets/Month
Model Number :
BXC
Product Name :
Battery-Power Transfer Cart
Usage :
Heavy Duty Material Transportation
Load Capacity :
1-300ton
Special Function :
Anti-Explosion,Heat-Resistant,Lifting,Customized
Material :
Steel
Transport Package :
The Whole Cart Will Be Packed by Tarp.
Specification :
2000*2000*500
Trademark :
BETTER
Origin :
Xinxiang
HS Code :
84289090
Production Capacity :
50 Sets/Month
Description
250ton China Supply Foundry Plant Use Steel Motorized Handling Transport Transfer Cart

Product Description

This China-made electric transfer cart features a quadruple-girder frame and heat-resistant protection for handling 250-ton ladles and castings. With explosion-proof motors and IP67-rated electronics, it withstands extreme foundry conditions. The intelligent control system enables precise ladle positioning and pouring assistance through laser ranging technology. Adopted by major foundries, it improves transport efficiency by 60% while enhancing safety in high-temperature operations.

Detailed Photos

250ton China Supply Foundry Plant Use Steel Motorized Handling Transport Transfer Cart

Product Parameters

Model BXC-2t BXC-5t BXC-10t BXC-16t BXC-20t BXC-25t BXC-30t BXC-40t BXC-50t BXC-63t BXC-80t BXC-100t BXC-150t
Rated Load(t) 2 5 10 16 20 25 30 40 50 63 80 100 150
Table Size (mm) Length(L) 2000 3500 3600 4000 4000 4500 4500 5000 5500 5600 6000 6500 10000
Width(W) 1500 2000 2000 2000 2200 2200 2200 2500 2500 2500 2600 2800 3000
Height(H) 450 500 500 550 550 600 600 650 650 700 800 900 1200
Wheel Base(mm) 1200 2500 2600 2800 2800 3200 3200 3800 4200 4300 4700 4900 7000
Rail Inner Gauge(mm) 1200 1435 1435 1435 1435 1435 1435 1435 1435 1435 1800 2000 2000
Wheel Diameter (mm) 270 270 300 350 350 400 400 500 500 600 600 600 600
Wheel Quantity 4 4 4 4 4 4 4 4 4 4 4 4 8
Ground Clearance(mm) 50 50 50 50 50 50 50 50 50 75 75 75 75
Running Speed (m/min) 0-25 0-25 0-25 0-20 0-20 0-20 0-20 0-20 0-20 0-20 0-20 0-20 0-18
Total Power(kw) 2 3 2.2 2.2 2.2 3 3.5 4 5 6.3 8 10 15
Battery Capacity(Ah) 150 180 180 200 220 220 260 300 330 400 400 440 600
Battery Voltage(V) 48 48 48 48 48 48 48 48 48 48 72 72 72
Running Time When Full Load 4.32 5.4 4.8 4.3 4 4 3.5 3.6 3.3 3 3.6 3.2 2.9
Running Distance for One Charge(km) 6.5 8.1 7.2 5.1 4.8 4.8 4.2 4.3 4 3.6 4.3 3.8 3.2
Max Wheel Load(KN) 14.4 25.8 42.6 64.5 77.7 94.5 110.4 142.8 174 221.4 278.4 343.8 265.2
Recommended Rail Model P15 P18 P18 P24 P24 P38 P38 P43 P43 P50 P50 QU100 QU100
Applicatin
Circulation within the large casting workshop
In the heavy casting workshop, it is responsible for transporting super-large castings weighing hundreds of tons (such as machine tool bases and large gear blanks) from the pouring area to the cooling area, cleaning area or storage area.
The mold is matched with the smelting equipment
It serves between large melting furnaces (such as electric furnaces) and the molding area, undertaking the fixed-point and safe transportation tasks of heavy steel ladles or large molds.
Transportation of heavy materials across workshops
As the core hub for heavy logistics within the foundry, it connects different workshops such as smelting, molding, and cleaning, achieving efficient and reliable cross-regional transportation of heavy materials.
Core performance and supply advantages
It adopts a sturdy steel structure to ensure the rigidity of the equipment under a maximum load of 250 tons. As equipment directly supplied by Chinese factories, it combines the reliability of heavy equipment with highly competitive cost-effectiveness.
250ton China Supply Foundry Plant Use Steel Motorized Handling Transport Transfer Cart

Our Advantages

---- Low noise It causes low noise level.
---- Maximum safety Offers guarantee of maximum safety for operators and for the material handled. We really care about the safety of everyone involved in the job.
---- Easy for operation These vehicles are easy to drive, so as soon as you get it you will be able to use it to transport your loads. We will support you to make the best out of your heavy load transporter.
---- Easy to implement into manufacturing process Operates on standard floors; Do not require complex or permanent installation
---- Suitable for All Kinds of Weight The steering battery powered trolley is superb for handling both small and extremely huge loads for its modular fabrication and its high payloads: up to 300 ton for each trolley.

Packaging & Shipping

*For lenght is less than 6m, the width is less than 2.2m. It will be transported by 20ft container. If the length is longer than 5.9m and less than 12m, it will be transported by 40ft container. If the quantity is 2 sets or 3 sets, they can be transported by full container. If the quantity is 1 set, it can be transported by LCL Container.
* If the length is less than 12m, the width is beyond 2.2m. It needs to be transported by flat rack (20 or 40 ft) . If the equipment is beyond above dimension, and quantity need to consider bulk cargo.
