Specifications
Brand Name :
Remarkable
Model Number :
BKPJ, KPD, KPX
Certification :
CE, SGS, ISO9001
Place of Origin :
Henan, China
MOQ :
1set
Price :
Price negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
660/Price negotiation
Delivery Time :
35-40 working days
Packaging Details :
1. Main body of the machine is packed with high-quality waterproof plastic cloth. 2. Electrical parts are specially protected, and the spare parts are packed in standard export fumigation free wooden boxes.
Product Name :
50 ton Motorized Rail-Guided Transfer Cart
Operation Type :
Remote+Hand Pendant
Running speed :
0-20/min (Stepless Speed-adjusting)
Power supply :
Rail/Cable/AC+DC motor/motorized
Load capacity :
1-1000 tons/Customized
key word :
rail transfer trolley
Application :
Industry Field/Workling Line/Transfer Materials
Wheels type :
Cast Wheel; Forged Wheel
Size :
customized
High Light :
material handling rail transfer cart,rail transfer carriage transport platform,rail flat flatbed car tow dolly
Description

50 Ton Motorized Rail-Guided Transfer Cart

The motorized rail-guided transfer cars are designed for industrial fields material transport. It is a kind of motorized material handling tool mounted and running on the steel track. The motorized transfer car is manufactured using the best grade material and is in conformity with international quality standards. The assortment of rail-guided cars is highly appreciated by the clients for their features such as longer functional life and low maintenance.

Remarkable rail transfer cart can handle upwards of 500ton and work well in areas with limited floor space. These materials Motorized transfer carts are more accommodating for moving long loads through restrictive passageways or doorways. Usually, the heavy loads Motorized transfer vehicles are used to accommodate the needs of a wide range of industries including Steel, Aluminum, Automotive, Heavy Manufacturing, and others. These electric transfer trolleys are designed to operate on floor-mounted rails and are used to transport heavy materials across crane bays or in areas not serviced by an overhead crane.

50 Ton Motorized Rail Guided Transfer Cart

Technical parameters for rail power transfer carts
Model KPG-6t KPG-10t KPG-16t KPG-25t KPG-40t KPG-63t KPG-100t KPG-160t KPG-200t
Rated load (t) 6 10 16 25 40 63 100 160 200
Countertop size(mm) Length 3600 3600 4000 4500 5000 5600 6300 8000 8200
Width 2000 2000 2200 2200 2500 2500 2800 2800 3000
Height 550 550 600 650 700 850 900 1100 1250
Speed(m/min) 30 30 30 30 25 25 20 20 18
Wheelbase A(mm) 2000 2200 2200 2500 2800 3200 3600 5000 5000
Track medial distance C(mm) 1435 1435 1435 1435 1435 1435 1650 2000 2000
Wheel diameter(mm) 400 400 400 500 500 600 700 700 700
Bottom clearance(mm) 50 50 50 60 60 60 60 70 70
Minimum turning radius 30 35 50 55 60 80 100 100
Power mode Battery/low-voltage rail/ Cable Drum/cable reels/Dragged Cable / busbar powered
Recommended track model 24kg/m 38kg/m 43kg/m QU80 QU100
Number of wheels 4 8
Maximum wheel Pressure (t) 1.91 3.21 4.87 7.5 11.5 16.9 27.6 22.8 28.5
Reference weight (t) 3.4 3.72 4.2 6 8.5 11.4 15.2 25.5 31.5
Note 1) Other gauges, table sizes, and load tonnages can be customized according to user requirements;
2) Imported and domestic industrial wireless remote-control devices are optional;
3) Optional imported wireless two-speed control;
4) Optional matching automatic parking, and alarming when encountering person 2 meters away.


50 Ton Motorized Rail Guided Transfer Cart

Applications

All kinds of material transport;
Connect different bays of an industrial plant;
Connect a production area with a warehouse or a yard;
Automatic feeding of a production area;
Relieve overhead cranes work;
Portable machine base;
Assembly mount;
Heavy equipment transporter with lift deck;
Pre-cast concrete production trolleys;
The portable base for jib arm with a spreader beam.
