Specifications
Brand Name :
Remarkable
Model Number :
RWP
Certification :
CE, ISO
Place of Origin :
Henan, China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
600
Delivery Time :
30-45 work days
Packaging Details :
1. Main body of the machine is packed with high-quality waterproof plastic cloth. 2. Electrical parts are specially protected, and the spare parts are packed in standard export fumigation free wooden boxes.
Power supply :
Maintenance free battery
Load :
35 tons
other name :
electric trackless transfer cart
Operation method :
Wireless remote control & Hand operate pendant
Traveling speed(m/min) :
0-30 (Stepless speed regulation)
Brake mode :
Electromagnetic brake
application area :
Material transportation
Move Way :
Forward, backward, turning while driving with no stop
Description

35 Ton heavy-duty modular transfer carts vehicle transfer carts

RMK transfer carts move loads of all types at ground level, for all industries and a huge variety of applications.These heavy-duty modular transfer carts are available in a wide range of capacities and dimensions to suit any requirement.They are equipped with all the safety devices needed for ground-level machinery movement.They are an important complement to cranes lifting heavy loads at ground level and the ideal solution for cargo transfer between ships.

There are two main types of transfer carts, according to movement type:

- Steerable transfer carts: These move in any direction. Available in battery powered version.

- Transfer carts on rails: These move in a straight line. Available in battery-powered or electric versions, with movement via a winder or power line.

RMK transfer carts move loads of all types at ground level, for all industries and a huge variety of applications.These heavy-duty modular transfer carts are available in a wide range of capacities and dimensions to suit any requirement. They are equipped with all the safety devices needed for ground-level machinery movement.They are an important complement to cranes lifting heavy loads at ground level and the ideal solution for cargo transfer between ships.

35 Ton Heavy Duty Modular Transfer Carts Vehicle Transfer Carts35 Ton Heavy Duty Modular Transfer Carts Vehicle Transfer Carts

35 Ton heavy-duty modular transfer carts vehicle transfer carts

We manufacture steerable (free-moving) transfer carts ranging from 10 to 60 tons. They are independent, battery powered and can move freely on flat ground, inside and outside the building. Battery powered rail-mounted transfer carts Rail-mounted transfer carts (straight line travel only) are manufactured in capacities ranging from 10 to 100 tons. They are battery powered and run on rails. Our rail-mounted transfer carts (straight line travel only) are manufactured in capacities ranging from 10 to 100 tons. They can be powered via a winder or a shielded cable.

We also manufactures rail vehicle transfer carts with capacities ranging from 60 to 150 tons, mainly used for moving trains for maintenance work. They are quick, safe and easy to move.

They are equipped with all the safety devices needed for ground-level machinery movement.They are an important complement to cranes lifting heavy loads at ground level and the ideal solution for transferring material.

- Battery charger

- Button panel control with 3 m hose

- Optional: Radio control

- Optional: Wooden blocks on frame

Technical parameters for electric transfer carts
1 rated load(t) 5 10 15 20 30 40 50 150
2 impacted rated load(t) 7.5 15 22.5 30 45 60 75 225
3 structure of frame steel plates welded, beam structure
4 max. wheel load(t) 2.8 4.3 4.8 5.6 7.7 10 12 27
5 ground requirement cement floor steel plate ground
6 table size(mm) 3000×2000 3600×2000 4000×2200 4500×2200 5000×2200 5500×2300

6000×

2300

10000×

3000

7 height of the whole cart(mm) 450 530 600 600 650 700 700 1200
8 ground clearance(mm) 50 75
9 wheels base(mm) 1500 1700 1800 2000
10 axles distance(mm) 2500 3100 3400 3900 4300 4800 5200 10000
11 turning radius(mm) 2501 3101 3401 3901 4301 4801 5201 10001
12 turning type turning while driving with no stop
13 control method for turning control button
14 turning structure mechanical
15 motor power(Kw) 3.5 5 6 7 10 12 15 15
16 wheel diameter(mm) Ф300 x 4 Ф350 x 4 Ф400 x 4 Ф400 x 6 Ф500 x 6 Ф600 x 8
21 battery model D-250 x 24 D-33 x 24 D-400 x 24 D-440 x 24 D-250 x 36 D-330 x 36 D-440 x 36 D-600 x 36
22 battery maintenance free of maintenance
23 charger's installation installed on cart split-type
24 charger function automatic charging
25 radar control 3-0.3m, automatic stop for obstacles
26 warning equipment sound and light
27 other functions turning light, night light and power display

35 Ton Heavy Duty Modular Transfer Carts Vehicle Transfer Carts35 Ton Heavy Duty Modular Transfer Carts Vehicle Transfer Carts35 Ton Heavy Duty Modular Transfer Carts Vehicle Transfer Carts35 Ton Heavy Duty Modular Transfer Carts Vehicle Transfer Carts35 Ton Heavy Duty Modular Transfer Carts Vehicle Transfer Carts35 Ton Heavy Duty Modular Transfer Carts Vehicle Transfer Carts35 Ton Heavy Duty Modular Transfer Carts Vehicle Transfer Carts35 Ton Heavy Duty Modular Transfer Carts Vehicle Transfer Carts35 Ton Heavy Duty Modular Transfer Carts Vehicle Transfer Carts35 Ton Heavy Duty Modular Transfer Carts Vehicle Transfer Carts35 Ton Heavy Duty Modular Transfer Carts Vehicle Transfer Carts
